Honda 08L04-S9V-100 Installation Instructions

INSTALLATION
INSTRUCTIONS
Put this information in the glove box with the vehicle owner's manual.
PARTS LIST
2 Frames A
2 Frames B
9 Pipes
Flap
L Brackets
4 Bracket covers A
4 Bracket covers B
8 Bolts
© 2010 American Honda Motor Co., Inc. – All Rights Reserved.
Accessory
LUGGAGE BASKET
P/N 08L04-S9V-100
8
8
8
8
4 Brackets B
8
8
TOOLS REQUIRED
Phillips screwdriver
10 mm Combination wrench
INSTALLATION
NOTE:
• Be careful not to damage the roof and other finished
surfaces of the body when installing the luggage
basket.
• Be careful before entering automatic car washes.
Compare the vehicle height limit of the automatic car
wash and the height of the vehicle.
• The maximum load capacity for this product is 50 kg
(110 lb); approximate product weight is 5 kg (12 lbs).
• Optional roof rack crossbars (sold seprately) are
required to install the luggage basket.
AII 43322 (1003)
Application
2011 PILOT
Screws
Self-tapping screws
Nuts
Washers
Square nuts
Socket bolts
Publications No.
AII 43322
Issue Date
MARCH 2010
1 of 4
08L04-S9V-1000-91
