1-800-669-9690
INSTALLATION INSTRUCTIONS
ROADMASTER, INC.
PARTS LIST:
1- RETRO PART (A) - Passenger side
1- RETRO PART (B) - Driver's side
WARNING:
IMPORTANT: All brackets must be assembled with all the bolts left loose for final adjustment &
positioning (before tightening) unless otherwise instructed. All bolts must be torqued for proper strength.
If more than one bolt is used per fastening point, the diagram may only show one.
• Use flat washers over all slotted holes
R
MOUNTING BRACKET KIT
5602 N.E. SKYPORT WAY
• DO NOT USE THIS DOCUMENT FOR CUSTOM FABRICATION AS THIS ILLUSTRATION MAY NOT SHOW ALL PARTS
OR STRUCTURAL COMPONENTS.
• ROADMASTER WILL NOT BE RESPONSIBLE FOR ANY DAMAGE OR INJURY RESULTING FROM ANY MODIFICATION
OR ALTERATION.
• OWNER MUST INSPECT ALL MOUNTS AND BRACKETS BEFORE EACH USE FOR CRACKS OR OTHER SIGNS OF
FATIGUE. ALSO INSPECT FASTENERS FOR PROPER TORQUE.
FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT
CAUTION:
IN DEATH, PERSONAL INJURY OR PROPERTY DAMAGE
O
A
D
PORTLAND, OR 97218
SAFETY CABLES MUST CONNECT THE TOWING
VEHICLE TO THE TOWED VEHICLE FRAME TO FRAME.
FOLLOW SAFETY INFORMATION IN WARRANTY PACKET
• Use lock washers on all fasteners
M
A
S
1-800-669-9690
FAX (503) 288-8900
KIT NO. 1007-2 RETRO
CAUTION
T
E
R
6/25/99
Advertisement
Related Manuals for Roadmaster 1007-2 RETRO
Summary of Contents for Roadmaster 1007-2 RETRO
-
Page 1: Installation Instructions
• DO NOT USE THIS DOCUMENT FOR CUSTOM FABRICATION AS THIS ILLUSTRATION MAY NOT SHOW ALL PARTS OR STRUCTURAL COMPONENTS. WARNING: • ROADMASTER WILL NOT BE RESPONSIBLE FOR ANY DAMAGE OR INJURY RESULTING FROM ANY MODIFICATION OR ALTERATION. • OWNER MUST INSPECT ALL MOUNTS AND BRACKETS BEFORE EACH USE FOR CRACKS OR OTHER SIGNS OF FATIGUE. - Page 2 104 ft./lb. 97ft./lb. All illustrations and specifications contained herein are based on the latest information available at the time of publication approval. ROADMASTER, INC. reserves the right to make changes at any time without notice in material, specification and models or to discontinue models.
-
Page 3: Hardware List
5602 N.E. SKYPORT WAY PORTLAND, OR 97218 1-800-669-9690 FAX (503) 288-8900 KIT NO. 1007-2 RETRO Congratulations! You have just purchased another fine Roadmaster product. Thank you. HARDWARE LIST: 2-1/2” X 3 ½” BOLTS 2-1/2” LOCK WASHERS 6-1/2” FLAT WASHERS 2-1/2” NUTS 2-1/4”...
