BUILD INSTRUCTIONS

NOTE: This kit includes fixings for both the original
:MOVE mini and :MOVE mini Mk2, so there may be spare
components left over after the build.
1
To use the Line Following board
with the Interface board, first
complete the build instructions
provided with the Interface Board.
2
To use with the :MOVE mini,
please see 'Use with :MOVE
mini' on the following page.
If you wish to use this board
separately connect the line
follow board to the interface
board in the order shown.
GND 0V
P15 R
3V3 3V
P16 L
GND 0V
