BUILD INSTRUCTIONS

SUPPLIED WITH THIS KIT:

1x
Servo & Tow Panel Front, Base & Rear
Gear & Connector
Pin Header
Base Panel
2x
1
Take the :MOVE mini and remove the front ':MOVE' piece, followed
by the SERVO:LITE board, and then the pen mounting plate above
the servos. Put these aside for now, you will need them later.
2x
Exterior Side
Bucket Panels Panels & Wheels
M3x10 Countersunk
Screw
M3x6 Screw
M3 Washer
NOTE: If not done already, the SERVO:LITE board
will need to be converted for use of three servos
with the pin header provided.
Visit kitronik.co.uk/3servo for the online guide.
Servo
Side Bucket
Connectors
Panel
5x
M2x16mm
Screw
8x
M2x6mm
Screw
M2 Nuts
