  • Page 1 GET TIPPING WITH THE :MOVE Mini TIPPER TRAILER ADD-ON...
  • Page 2 Put these aside for now, you will need them later. NOTE: If not done already, the SERVO:LITE board will need to be converted for use of three servos with the pin header provided. Visit kitronik.co.uk/3servo for the online guide.
  • Page 3 Install the tow panel at the rear of the :Move mini using two M3x10mm countersunk screws, passing through the hole in the base and threading into the connector below. Thread an M2x16mm screw halfway through the small hole. This will be the tow-bar to connect the trailer.
  • Page 4 Repeat steps 3-5 for the opposite side, making sure components are in reverse order. Place the servo onto the base panel and slot the connectors into the base from below with the flat edge facing inwards. Screw the servo into place with the M2x6mm bolts: these should pass through the servo and thread into the perspex.
  • Page 5 Slot the exterior side panel onto the base on the same side as the servo gear. Place the tipper bucket panel in the fully down position. Fit the nuts threaded on previously into the slots in the base panel from below and fit components together.
  • Page 6 Repeat step 9 to attach the second exterior panel on the opposite side. Make sure to slot the rear panel in as shown and tighten the screws in the base. Then insert the second M2x6mm screw into the rear panel with another M2 nut as shown using the previous method.
  • Page 7 :MOVE piece at the front. Tuck the loose wires under the pen mounting plate. NOTE: With the back of the board facing you - the third servo attaches to uppermost, right, set of pins. GET CODING! Visit kitronik.co.uk/5624-TT for help.
  • Page 8 • Soldering Iron • Knife This accessory requires modification to the Servo:Lite board and disables the on board ZIP LEDs. Visit kitronik.co.uk/3servo for the online guide. For more information on RoHs and CE please visit kitronik.co.uk/rohs-ce. Children assembling this product should be supervised by a competent adult.
