User Manual
02/18/04
I
NTRODUCTION
The BCM91125F evaluation board is an evaluation platform intended to support the needs of prospective
users of the BCM1125H processor. This user manual provides information on how to get the BCM91125F
evaluation board up and running quickly. This manual also describes how to locate, configure, and observe
the various connectors, switches, jumpers, and LEDs on the BCM91125F, allowing software development and
evaluation of the BCM1125H processor to begin.
For additional information on this board and the BCM1125H processor, go to:
http://sibyte.broadcom.com/public.
I I
TEMS NCLUDED WITH THE
The following items are included with the BCM91125F evaluation board shipment:
• BCM91125F evaluation board
• OCDemon Macraigor Systems Wiggler parallel port JTAG probe
• 120–240V AC to 5V DC power adapter
• Viosoft ARRIBA
• This document
F
EATURES
This section describes the BCM91125F's features.
H
ARDWARE
• BCM1125H processor
• Half-length PCI card form factor
• 128 MB of DDR SDRAM
• Two 10/100/1000 Mbps Ethernet interfaces with RJ45 connectors
• One UART with RS232 interface
• Universal 32-bit, 33/66-MHz capable PCI connector
• 16-MB Flash ROM
• Two SMBus channels with the following devices connected:
- RTC
- EEPROMs
- temperature sensor
• EJTAG connector
• Four-character LED display
Document 91125F-UM100-R
Section 1: Product Over v iew
S
HIPMENT
®
Embedded Edition CD
B roadc om C or por ati on
BCM91125F
Product Overview Page 1
