Legends
Beginner technique
Technique usable by a trained
practitioner of the activity
Technique for a certified
practitioner
Technique for a person trained and
certified in the activity
Expert technique
Technique only for experts in the
activity
PRODUCT EXPERIENCE - GRIGRI2
PRODUCT EXPERIENCE
To go beyond...
Welcome to "Product Experience".
Here you will find known usage techniques for certain products.
This technical information comes from the product knowledge of the Petzl team and from the
experience of users worldwide.
The level of experience necessary to perform each technique is indicated by a pictogram (see
opposite): beginner, certified, or expert.
Our goal is to (eventually) offer a complete set of techniques.
Your help is important to us; do not hesitate to give us your comments and suggestions.
Thank you and good reading.
The Product Experience
• is a supplement to the information in the Instructions For Use.
• is inseparable from the Instructions For Use.
ImPoRTANT / REmEmBER
• Read the instructions for use carefully before looking at the following techniques.
• You must have already read and understood the information in the Instructions For Use to be
able to understand this supplementary information.
• Mastering these techniques requires specific training.
• Work with a professional to confirm your ability to perform these techniques safely and
independently before attempting them unsupervised.
FAILURE TO HEED ANY OF THESE WARNINGS MAY RESULT
IN SEVERE INJURY OR DEATH
Anchor
Load
Climber
Fall
D145030A (180111)
GRIGRI EXPERIENCE
Hand
Harnesses
Victim
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GRIGRI2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Petzl GRIGRI2

Summary of Contents for Petzl GRIGRI2

  • Page 1 Welcome to “Product Experience”. Here you will find known usage techniques for certain products. This technical information comes from the product knowledge of the Petzl team and from the experience of users worldwide. The level of experience necessary to perform each technique is indicated by a pictogram (see opposite): beginner, certified, or expert.

  • Page 2: Table Of Contents

    GRIGRI EXPERIENCE Summary • Reminder of rope compatibility: GRIGRI and GRIGRI2 p. 3 > Belaying / Protecting Belaying reminders: errors to avoid • p. 4 • Dynamic belaying p. 8 • Belaying with the GRIGRI anchored to the ground: WARNING, Danger! p. 9 •...

  • Page 3: Reminder Of Rope Compatibility Grigri And Grigri2

    Whenever you need to use a rope other than your usual rope, take care and familiarize yourself with its behavior with the GRIGRI in belaying and descending. GRIGRI2 GRIGRI ropes mm 8,9 9 READ AND UNDERSTAND THE INSTRUCTIoNS FoR USE PRODUCT EXPERIENCE - GRIGRI2 D145030A (180111)

  • Page 4: Belaying / Protecting

    This technique allows the braking side of the rope to always be held by the hand (with at least three fingers) and it limits the risk of blocking the cam’s action. READ AND UNDERSTAND THE INSTRUCTIoNS FoR USE PRODUCT EXPERIENCE - GRIGRI2 D145030A (180111)
  • Page 5 Note that the use of incorrect belay technique is the primary risk factor in an accident, especially when the belayer is surprised by a fall. If you recognize yourself in any of these illustrations of incorrect technique, adopt the technique presented at the beginning of this paragraph. READ AND UNDERSTAND THE INSTRUCTIoNS FoR USE PRODUCT EXPERIENCE - GRIGRI2 D145030A (180111)
  • Page 6 In this case, the belayer burns his hand with the rope and worse, prevents the GRIGRI’s cam from rotating, which then cannot brake the rope. Here also, the climber falls to the ground. READ AND UNDERSTAND THE INSTRUCTIoNS FoR USE PRODUCT EXPERIENCE - GRIGRI2 D145030A (180111)
  • Page 7 To finish, ground falls are often the result of multiple factors: poor technique, inattention, etc. It is up to you to limit these factors. READ AND UNDERSTAND THE INSTRUCTIoNS FoR USE PRODUCT EXPERIENCE - GRIGRI2 D145030A (180111)

  • Page 8: Dynamic Belaying

    It takes practice to master dynamic belaying. To practice, start with falls sufficiently high relative to the ground (for example, when the climber is nearing the end of a pitch). READ AND UNDERSTAND THE INSTRUCTIoNS FoR USE PRODUCT EXPERIENCE - GRIGRI2 D145030A (180111)

  • Page 9: Belaying With The Grigri Anchored To The Ground: Warning, Danger

    In addition, with a GRIGRI anchored to the ground, controlling the descent is more difficult than with the GRIGRI on the belayer because the weight of the climber cannot be felt. Finally, this technique does not allow for dynamic belaying. READ AND UNDERSTAND THE INSTRUCTIoNS FoR USE PRODUCT EXPERIENCE - GRIGRI2 D145030A (180111)

  • Page 10: Unblocking A Rope That Is Jammed Behind The Cam

    Unjamming, if the climber side of the rope is not under tension: push on the device to reposition the climber side of the rope in the cam groove READ AND UNDERSTAND THE INSTRUCTIoNS FoR USE PRODUCT EXPERIENCE - GRIGRI2 D145030A (180111)

  • Page 11: Multipitch Climbing

    Never let go of the braking side of the rope. To arrest a fall, firmly grip the braking side of the rope while pulling downward on it. READ AND UNDERSTAND THE INSTRUCTIoNS FoR USE PRODUCT EXPERIENCE - GRIGRI2 D145030A (180111)

  • Page 12: Belaying A Second Directly Off The Anchor

    (especially with thin ropes). In addition, the risk of blocking the cam is greater. We therefore recommend the preceding technique, using a directional point. READ AND UNDERSTAND THE INSTRUCTIoNS FoR USE PRODUCT EXPERIENCE - GRIGRI2 D145030A (180111)

  • Page 13: A Self-Belaying Is Prohibited

    Additionally, in case of a fall, the GRIGRI can be blocked against the rock, the positioning system (positioning strap), or other, thus negating its braking function. The climber could fall to the ground. Finally, remember that any product modification outside of PETZL facilities is formally prohibited (see Instructions for use).

  • Page 14: Descending

    While tethered to the belay anchor, install the rope in the GRIGRI, making sure to place it in the device in the right direction. Connect the GRIGRI to the harness with a locking carabiner. Lock the carabiner. READ AND UNDERSTAND THE INSTRUCTIoNS FoR USE PRODUCT EXPERIENCE - GRIGRI2 D145030A (180111)
  • Page 15 Always hold the braking side of the rope. Do not forget to tie a knot in the bottom end of the rope. BRAKING READ AND UNDERSTAND THE INSTRUCTIoNS FoR USE PRODUCT EXPERIENCE - GRIGRI2 D145030A (180111)

  • Page 16: Descending On One Strand With Additional Braking

    GRIGRI. Make sure to correctly lock the tie-off. You may let go of the braking side of the rope only when the device is tied off. READ AND UNDERSTAND THE INSTRUCTIoNS FoR USE PRODUCT EXPERIENCE - GRIGRI2 D145030A (180111)

  • Page 17: Lowering With The Grigri On The Harness, Using A Directional

    The belayer pulls the handle while holding the braking side of the rope. Never let go of the braking side of the rope. Accessories / Accessoires FREINO READ AND UNDERSTAND THE INSTRUCTIoNS FoR USE PRODUCT EXPERIENCE - GRIGRI2 D145030A (180111)

  • Page 18: Lowering From A Fixed Anchor-Point

    To lower the person, the belayer pulls the handle while holding the braking side of the rope. Never let go of the braking side of the rope. READ AND UNDERSTAND THE INSTRUCTIoNS FoR USE PRODUCT EXPERIENCE - GRIGRI2 D145030A (180111)

  • Page 19: Self-Lowering

    Always hold the braking side of the rope. Do not forget to tie a knot in the bottom end of the rope. BRAKING READ AND UNDERSTAND THE INSTRUCTIoNS FoR USE PRODUCT EXPERIENCE - GRIGRI2 D145030A (180111)

  • Page 20: Climbing / Progressing

    The GRIGRI is useful for short rope ascents. It is also used on big walls in cleaning (useful for cleaning slab pitches). Tether yourself to your ascender. Always hold the braking side of the rope. READ AND UNDERSTAND THE INSTRUCTIoNS FoR USE PRODUCT EXPERIENCE - GRIGRI2 D145030A (180111)

  • Page 21: Tensioning A Tyrolean

    Unlocking tip: use a TRAXION pulley (or other ascender) placed on your tyrolean as shown. Pull on the free end to create slack between the TRAXION pulley and the GRIGRI. Pull the handle. READ AND UNDERSTAND THE INSTRUCTIoNS FoR USE PRODUCT EXPERIENCE - GRIGRI2 D145030A (180111)
