Regen Resistor Sizing and Configuration

1.3: Regen Circuit Wiring

This section describes the wiring of the regen resistor connections.

1.3.1: Electrical Codes and Warnings

Be sure that all wiring complies with the National Electrical Code (NEC) or its national equivalent,
and all prevailing local codes.
DANGER: Hazardous voltages.
!
Exercise caution when installing and adjusting.
Failure to heed this warning can cause equipment damage, injury, or death.
DANGER
Risk of electric shock.
!
High-voltage circuits on J1, J2, and J3 are connected to mains power.
Failure to heed this warning can cause equipment damage, injury, or death.
DANGER
Do not ground mains-connected circuits.
!
With the exception of the ground pins on J1, J2, and J3, all of the other circuits on
these connectors are mains-connected and must never be grounded.
Failure to heed this warning can cause equipment damage.
WARNING
