Rcom Juragon PX-20R User Manual page 2

9. How to start incubation
▶ If you connect incubator with power cord, it starts incubation
with existing temperature and humidity.
( Factory default setting-Temp.:26.1℃/ Humidity: 80% )
There can be some odor the first time you use
the incubator, that is normal.
10. How to Terminate Incubation
▶ After all eggs are hatched, you should take off the power cord for incubation termination.
If you leave the incubator alone without drying water after high humidity incubation,
the water inside of incubator condense and make waterdrop at the LCD display or
control device. For preventing this problem, disassemble main body 1 and 2, and
dry completely before storing. ( You can dry the incubator as operating the
incubator for about 1 to 2 hours after removing water.)
11. How to Supply Water for Humidity Maintenance
▶ Check the water everyday, and fill the hole with clean water.
The styrofoam ball floats on and
blocks the hole when full.
Check water level every day on incubation period,
and refill fully with warm water.
12. How to set Temperature
TEMP + TEMP + HUMI + HUMI +
TEMPERATURE HUMIDITY
CAL CAL
TEMP - TEMP - HUMI - HUMI -
HEATING HUMIDIFICATION
D.T.G. D.T.G.
TEMP.GAP WATER EMPTY
incubator
▶ If you press button, display will blink.
SET SET
HUMI + HUMI +
TEMPERATURE HUMIDITY
CAL CAL
TEMP - TEMP - HUMI - HUMI -
HEATING HUMIDIFICATION
D.T.G. D.T.G.
TEMP.GAP WATER EMPTY
incubator
( ① Keep pressing the button)
▶ In a state of button is pressed, adjust the
SET SET
temperature you want with or
TEMP + TEMP + TEMP - TEMP -
Temperature setting will be completed when you remove
your finger from the button, and present temperature
will be indicated.
If you set the incubator under a direct ray of light or If you set the incubator under a direct ray of light or
too cold spot, the incubator temperature too cold spot, the incubator temperature
can be high or low than setting temperature . can be high or low than setting temperature .
14. How to Turn ON/ OFF Daily Temp. Gap
TEMP + TEMP + HUMI + HUMI +
TEMPERATURE HUMIDITY
CAL CAL
TEMP - TEMP - HUMI - HUMI -
HEATING HUMIDIFICATION
D.T.G. D.T.G. SET SET
TEMP.GAP WATER EMPTY
incubator
(Keep pressing the button)
Temp. Gap lamp will light on during daily temperature gap is operating.
With this function, the temperature will go up 1.5℃ for about 3hours per day.
Ex) If setting temperature is 28.5℃, this function makes the incubator keep 30℃ for 3 hours per day.
15. How to turn off Humidification Function
▶ You can turn off humidification function when you don't fill water with your incubation
or when you need low humidity incubaion.
▶ Keep pressing SET button, and press HUMI- button until OFF indicated.
(OFF indicated when the humidity is under 40%)
PX-20R(Standard)
13. How to set Humidity
TEMP + TEMP +
TEMPERATURE HUMIDITY
CAL
TEMP - TEMP -
HEATING HUMIDIFICATION
D.T.G. D.T.G.
TEMP.GAP WATER EMPTY
incubator
▶ If you press button, display will blink.
SET SET
TEMP + TEMP +
TEMPERATURE HUMIDITY
CAL
TEMP - TEMP -
HEATING HUMIDIFICATION
D.T.G. D.T.G.
TEMP.GAP WATER EMPTY
incubator
( ① Keep pressing the button)
▶ In a state of button is pressed, adjust the
SET SET
humidity you want with or
button.
HUMI + HUMI +
Humidity setting will be completed when you remove
your finger from the button, and present inner humidity
will be indicated.
Temperature and humidity can be against
from normal setting extent according to
the surrounding environment.
What is Daily Temperature Gap Function?
▶
It is artificial promotion of nature condition of
the highest temperature time zone. By upraising the temperature
at the specific time zone, it helps achieving the highest hatching success.
SET
▶ Keep pressing SET button and press
Then, lamp will light on indicating this function is operating.
If lamp is off, it means this function is turned off.
16. How to Set Abnormal High or Low Temperatue Alarm
Digital Incubator
www.R-com.co.kr
▶ What is Abnormal High or Low Temperature Alarm?
It is alarm soulds when incubator temperature is higer or lower than setting value because of various
reasons such as room temperature change or disorder of temperature controlling system.
※ How to Set
SET
Press
SET button for
over 5Sec.
* Max. abnormal temp. alarm limit (0.0℃ ~ 5.0℃ Default Setting:0.0℃)
* Min. abnormal temp. alarm limit (0.0℃ ~ -5.0℃ Default Setting:0.0℃)
17. Change Cels.&Fahr.
▶ Press
TEMP + TEMP +
at the same time, and
Then, press
18. How to Calibrate Temp.(Humidity)
This calibration function is to reset the temperature and humidity of the incubator to correct values using
your thermometer and hygrometer. It is better not to calibrate the incubator as normal thermometer and
CAUTIONS
hygrometer are not reliable than incubator factory setting.
How to calibrate : Fill Vermiculite to three fourths of the internal tray. Fix temperature or hygrometer at 2 cm above
the bottom of the tray and operate it for one hour before starting its calibration.
* Be sure to check
▶ How to Calibrate Temp. (or Humidity):
Turn on the incubator, and press TEMP+(or HUMI+) and TEMP-( or HUMI-) button at the same time for about 5sec.
Then, "CA" will show on the display. Here, set the required temperature (or humidity)
with TEMP+(HUMI+) or TEMP-(HUMI-) button, and press "SET" button.
- After Calibration -
If you can not rely on your thermometer or hygrometer, you can initialize the incubator to factory setting.
(Refer to Incubator Initialization)
HUMI + HUMI +
CAL
HUMI - HUMI -
19. Incubator Initialization
( ALL RESET )
It is for initializing the incubator setting or calibration to factory setting
when you handle improperly so that the value changed.
Unplug the power supply. And, hold SET button as picture①. Re-plug the power supply as picture②.
Then, rSt will show on the display, and the incubator will be initalized to factory setting.
①
Keep pressing SET button
CAL
TEMP + TEMP +
HUMI - HUMI - TEMPERATURE
CAL
TEMP - TEMP -
HEATING
D.T.G. D.T.G.
TEMP.GAP
20. How to Clean after Hatching
button.
HUMI - HUMI -
▶ Pull out the electric cord from connecting jack,
and also take out the plug from the outlet.
▶ Unlock three of locking buttons at the front and back of incubator,
and disassemble the incubator.
▶ Disassemble the incubator. The bottom part shall be thoroughly cleaned
with water and dried.The upper parts shall be naturally dried in order to
remove moisture inside of the incubator.
Assemble the parts in the reverse order of disassembly.
▶In case of you operate humidification function, there can be moss on the
humidification heating part ⓐ. It doesn't effect in function,
and you just need to clean it with soft brush after hatching.
Do not inflict an impact to the humidification heating part ⓐ.
Or, it will be damaged.
Do not clean the product with organic solvents
such as benzene and paint thinner.
21. Specification
D.T.G. button.
D.T.G.
Power
Temp. limits
Temp. Accuracy
Working Temperature Ideal : 22℃ ~ 25℃
Humidity Limits
Humidity Accuracy
Power Consumption
Capacity
Net Weight
Size
Fuse Standard
Hatching result can be changed by a large number
of factors. Autoelex Co.,Ltd.
will not be held responsible for loss of eggs or reptiles under any circumstances
such as hatching failure, user's carelessness, power failure, or malfunction.
SET
Set required Set required
high range with high range with
UP / DOWN button UP / DOWN button
button and button
TEMP - TEMP -
repeat
CA will show on Temp. display.
button. It will change.
SET SET
CAUTIONS before you calibrate temperature or humidity.
For returning to the factory setting
②
Re-plug the power supply
HUMI + HUMI +
HUMIDITY
CAL
+
HUMI - HUMI -
HUMIDIFICATION
SET SET
WATER EMPTY
incubator
HOLD
Visit our web site (www.r-com.co.kr) for more information on our
products and other informations.
AC 100V~120V, 50/60Hz / AC 220V~240V, 50/60Hz
Update of information : download the necessary information
20℃ ~ 42℃(68℉~ 107.6℉) from resource room in Rcom homepage.
R-com digital reptile incubator is designed for easy and convenient use.
± 0.5℃
For the improvement of the functions of the incubator, design,
Min. 20℃ / Max. 26℃
how to use, etc. can be changed without notice in advance.
40% ~ 95% ( It can be changed according to the conditions )
± 5%
Average 48W
10~120 Eggs Available at once
4.35 Kg
(W)500×(L)410×(H)160 (mm)
250V 2.0A (Ø5×20mm)
SET
Set required Save setting and
low range with pass to current
UP / DOWN button temp. & humid.
indication
TEMP + TEMP + HUMI + HUMI +
TEMPERATURE HUMIDITY
CAL CAL
①
TEMP - TEMP - HUMI - HUMI -
HEATING HUMIDIFICATION
D.T.G. D.T.G. SET SET
TEMP.GAP WATER EMPTY
incubator
① ②
(Keep pressing the button)
③
"rSt" will show on the display as below,
and the incubator initialize to factory setting.
=
TEMP + TEMP + HUMI + HUMI +
TEMPERATURE HUMIDITY
CAL CAL
TEMP - TEMP - HUMI - HUMI -
HEATING HUMIDIFICATION
D.T.G. D.T.G. SET SET
TEMP.GAP WATER EMPTY
incubator
back
ⓐ
COMPANY : #612 DukAm-Ri, JuChon-Myeon,
●
: GimHae-City, GyeongNam, KOREA
TEL : 82-55-337-2560 (Direct to sales team)
●
: 82-55-337-2561-3, 2567 (Office)
FAX : 82-55-337-2568
●
E-MAIL : auto@autoelex.com ( Sales team )
●
