ultego® III perfect

Service loop 3 ("LOOP 3")

Service loop 3 shows the monthly values. LCD button 1 is used to select a month out of the 18 previous months. The data for
that month are then opened with LCD button 2. Each further press of LCD button 2 shows the next value for the selected
month.
...
After the last display, the previously selected set day is displayed again. Pressing LCD button 1 selects the next set day.
G.83.0101
ultego® III perfect
ista International GmbH – Grugaplatz 2 – D-45131 Essen
Head of the loop
Set day for December 2005
Set day for November 2005
...
Set day for July 2004
using LCD button 2:
Quantity of heat on the set day
Tariff register 1 on the set day
Volume on the set day
Max. flowrate on the set day,
at 2s intervals with date stamp
Max. heat power on the set day,
at 2s intervals with date stamp
Max. temperatures on the set day,
at 2s intervals with date stamp
for flow and return maximum
Missing time count on the set day
NOTE:
If you want to drop out and go directly to the next loop, choose a monthly value by pressing LCD but-
ton 2 and then press LCD button 1.
