TM
EconoScan II
Barcode Scanner
Quick Start Manual
Check Version

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EconoScan II and is the answer not in the manual?

Questions and answers

Summary of Contents for IDTECH EconoScan II

  • Page 1 EconoScan II Barcode Scanner Quick Start Manual Check Version...
  • Page 2: Fcc Warning Statement

    FCC WARNING STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
  • Page 3: Limited Warranty

    ID TECH is a registered trademark of International Technologies & Systems Corporation. EconoScan II and Value through Innovation are trademarks of International Technologies & Systems Corporation...
  • Page 4 Section 1 INTRODUCTION Indicator cable Scan window Trigger...
  • Page 5 Section 2 INSTALLATION AND OPERATION Installing the Keyboard Wedge Reader To install a keyboard wedge reader, follow the steps below: 1. Turn off the power of the PC or Terminal. 2. Unplug keyboard from the PC or Terminal. 3. Make sure you have the Y cable with appropriate Connector Type for your PC or Terminal.
  • Page 6 Installing the USB Reader 1、Insert USB Cable (RJ45 male head) to the scanner (reader) 2、Insert USB Cable (USB male head) into Host's (female) USB connector...
  • Page 7 Interface setting and factory default Scan in following order to set up the associated interface: 1、Read the “Configuration ON” barcode to enter the setting mode. 2、Scan the associated interface or Default from the right column. 3、Exit the setting mode by scanning the “Configuration OFF”. PS/2 Configuration ON RS232...
  • Page 8: Troubleshooting

    Section 3 TROUBLESHOOTING Troubleshooting assistance for common problems:  No Beep Possible Reason: The interface cable has come off. Solution: Re-plug the cable.  The Scanner does not output data. Possible Reason: Set-up error. Solution: Re-set interface from the manual. ...
  • Page 9: Specification

    Section 4 SPECIFICATION...
  • Page 10 Section 5 READING MODE SETTINGS Trigger Mode Configuration ON Auto Power off Mode(Default) Configuration OFF Continuous/Trigger OFF Mode Test Mode...
  • Page 11: Testing Codes

    Section 6 TESTING CODES Code 128 UCC/EAN-128 UPC-E UPC-A Interleaved 2 of 5 Code 39 Full User’s Manual is available for download on www.idtechproducts.com...
  • Page 12 ID TECH 10721 Walker Street Cypress, CA 90630 (714) 761-6368 www.idtechproducts.com 80103501-001 rev.C...
