Clenergy by email on sales@clenergy. when delivering ground mount projects. com.au, or contacting your local distributor. Please review this instruction guide thoroughly...
583/446 501/501 583/446 501/501 583 / 446 583 / 446 Max/Min post height above the ground, 1000/863 1300/1300 1000/863 1300/1300 1000 / 863 1000 / 863 mm, from Clenergy Spacing(S),m 3.50 3.35 3.40 3.25 2.95 1.95 Max Vertical Uplift Reaction,kN 12.3...
Page 4
The minimum post embedment depth in the pier shall be approximately 0.9 of the pier depth. ≥ 300 Compact sand - (*): when using Clenergy East-West adaptor (if different to the 150 - 300 Medium dense sand spacing without adaptor);...
(2) Apply lubricant (grease or 40# engine oil) to fasteners prior to tightening to avoid galling or seizing in the threads; Installation Guide_PV-ezRack_SolarTerraceII-A_AU_V2.0 page of 21 1/10 Duerdin Street, Clayton VIC 3168 Australia Tel: +61 3 9239 8088 Fax: +61 3 9239 8024 E-mail: sales@clenergy.com.au www.clenergy.com.au...
Page 8
Please refer to safe torques defined in this guide as shown in below figure. In case power tools are required, Clenergy recommends the use of low speed only. High speed and impact drivers increase the risk of bolt galling (deadlock) If deadlock occurs and you need to cut fasteners ensure that there is no load on the fastener before you cut it.
In case you need to do any on-site modifications or alteration of the system in a way that would be different from the construction drawing please provide marked up drawings/sketches for Clenergy’s review prior modification for comment and approval. INTRODUCTION Below are the side view drawings of support for 60 cell panels(up to 1700 x 1100 mm)and 72 cell panels (up to 2000 x 1100 mm) at 20°...
Page 10
Apply Zinc Coating to upper section project drawing. If you don’t have this of C Post after ramming document, please contact Clenergy technical support. Mark the positions of the posts using a string and tape measure or GPS and drive the posts into the ground.
Page 11
Recommended torque: Bolt M12 50~55N·m To achieve earthing/ grounding function using set screws Fig. 2 Installation Guide_PV-ezRack_SolarTerraceII-A_AU_V2.0 page of 21 1/10 Duerdin Street, Clayton VIC 3168 Australia Tel: +61 3 9239 8088 Fax: +61 3 9239 8024 E-mail: sales@clenergy.com.au www.clenergy.com.au...
Page 12
5.4 Pre-assembled Support Installation Place the (pre-assembled) support into post head as shown in Fig.5. Fig. 5 Installation Guide_PV-ezRack_SolarTerraceII-A_AU_V2.0 page of 21 1/10 Duerdin Street, Clayton VIC 3168 Australia Tel: +61 3 9239 8088 Fax: +61 3 9239 8024 E-mail: sales@clenergy.com.au www.clenergy.com.au...
Page 14
④ Rotate the orientation of T head to fit the Tube Support to the post brace. Fig. 11 Installation Guide_PV-ezRack_SolarTerraceII-A_AU_V2.0 page of 21 1/10 Duerdin Street, Clayton VIC 3168 Australia Tel: +61 3 9239 8088 Fax: +61 3 9239 8024 E-mail: sales@clenergy.com.au www.clenergy.com.au...
Page 16
Connecting Rails on Structure system are not recommended. Fig. 17 7c. Racking System installation is complete. Fig. 18 Installation Guide_PV-ezRack_SolarTerraceII-A_AU_V2.0 page of 21 1/10 Duerdin Street, Clayton VIC 3168 Australia Tel: +61 3 9239 8088 Fax: +61 3 9239 8024 E-mail: sales@clenergy.com.au www.clenergy.com.au...
Page 17
Key point: When replacing a single defective PV Module, it’s required to replace the Grounding Clip under the PV Module. Installation Guide_PV-ezRack_SolarTerraceII-A_AU_V2.0 page of 21 1/10 Duerdin Street, Clayton VIC 3168 Australia Tel: +61 3 9239 8088 Fax: +61 3 9239 8024 E-mail: sales@clenergy.com.au www.clenergy.com.au...
Page 18
PV Module is not finalized. Only slightly tighten bolts to keep PV Modules in place. Installation Guide_PV-ezRack_SolarTerraceII-A_AU_V2.0 page of 21 1/10 Duerdin Street, Clayton VIC 3168 Australia Tel: +61 3 9239 8088 Fax: +61 3 9239 8024 E-mail: sales@clenergy.com.au www.clenergy.com.au...
Page 19
Note: before installation, make sure there will be enough clearance between screw and module of Universal Clamp as shown in figure below . Fig. 24 Installation Guide_PV-ezRack_SolarTerraceII-A_AU_V2.0 page of 21 1/10 Duerdin Street, Clayton VIC 3168 Australia Tel: +61 3 9239 8088 Fax: +61 3 9239 8024 E-mail: sales@clenergy.com.au www.clenergy.com.au...
Page 20
PV Module is closely in contact with Universal Clamp as shown in right Figure. Fig. 27 Installation Guide_PV-ezRack_SolarTerraceII-A_AU_V2.0 page of 21 1/10 Duerdin Street, Clayton VIC 3168 Australia Tel: +61 3 9239 8088 Fax: +61 3 9239 8024 E-mail: sales@clenergy.com.au www.clenergy.com.au...
Page 21
5.8.4 Now the installation is complete as shown in figure below. Please recheck all Bolts and fasten them tightly using the recommended torque. Fig. 29 Installation Guide_PV-ezRack_SolarTerraceII-A_AU_V2.0 page of 21 1/10 Duerdin Street, Clayton VIC 3168 Australia Tel: +61 3 9239 8088 Fax: +61 3 9239 8024 E-mail: sales@clenergy.com.au www.clenergy.com.au...
Clenergy’s written installation instructions, or if the Product has been modified, repaired, or reworked in a manner not previously authorized by Clenergy IN WRITING, or if the Product is installed in an environment for which it was not designed. Clenergy shall not be liable for consequential, contingent or incidental damages arising out of the use of the Product by Purchaser under any circumstances.
