W_DISABLE#
20
LED_WWAN#
42
6,23,25,28,31
NC
,33,48
2.3
Package Dimensions
SIM7100-PCIE_Hardware_Design_V1.05
Optional: Receiver negative output
I
RF Control Input
O
Network Status Indication output
--
No connection
Figure 3: Dimensions of SIM7100-PCIE (Unit: mm)
