Thermostatic Recessed Dual Control Shower Valve
Installation Instructions & User Guide
Models covered: N2 SHCVO C / G, AR3 SHCVO C, PM2 SHCVO C, RS
SHCVO C, AR3 SHCMT C, DSC SHCVO C
Installer, when you have read these instructions please ensure you leave
them with the user.
IMPORTANT: Please keep these instructions for future reference and request of replacement parts
Advertisement
Table of Contents
Related Manuals for Bristan N2 SHCVO C
Summary of Contents for Bristan N2 SHCVO C
- Page 1 Thermostatic Recessed Dual Control Shower Valve Installation Instructions & User Guide Models covered: N2 SHCVO C / G, AR3 SHCVO C, PM2 SHCVO C, RS SHCVO C, AR3 SHCMT C, DSC SHCVO C Installer, when you have read these instructions please ensure you leave them with the user.
-
Page 2: Table Of Contents
Contents Thank you for choosing Bristan, the UK’s leading showers and taps expert. We have designed this product with your enjoyment in mind. To ensure that it works to its full potential, it needs to be fitted correctly. These fitting instructions have been created to give you all of the information you need and, if you need any further help, please do not hesitate to give us a call on 0330 026 6273. -
Page 3: Important Safety Information
Important Safety Information • Please read these instructions thoroughly and retain for future use. • All products manufactured and supplied by Bristan are safe provided they are installed, used correctly and receive regular maintenance in accordance with these instructions. •... -
Page 4: General Information
General information This product has been tested to the Water Regulations Advisory Scheme (WRAS) and satisfies the requirements of the Water Supply (Water Fittings) Regulations 1999 and current bylaws. For full Installation Requirements & Notes (IRN) please visit www.wras.co.uk/directory. BS7600 recommends the temperature of stored water should never exceed 65ºC. A stored water temperature of 60ºC is considered sufficient to meet all normal requirements and will minimise the build up of lime scale in hard water areas. -
Page 5: Product Features
PM2 SHCVO C shown Note: The N2 SHCVO C/G & RS SHCVO C can either be installed portrait or landscape. Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors. -
Page 6: Specifications
Important: Minimum wall cavity depth: 35mm Min. – Max. concealing plate thickness: 45 – 75mm For full dimensional drawings please visit: www.bristan.com Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors. -
Page 7: Pack Contents
Pack Contents – N2 SHCVO C / G 1. Concealing plate x1 2. Handles x2 3. Shrouds x2 4. Screws x2 5. Valve body x1 6. Valve body fixings x2/2 7. Inserts x2 8. Flow regulators x2 9. Filter washers x2 10. - Page 8 Pack Contents – AR3 SHCVO C Concealing plate x 1 Valve body x 1 Handles x 2 Valve body fixings x2/2 Inserts x 2 Flow Regulators x 2 Filter Washers x 2 Wall outlet x 1 Shrouds x2 Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
- Page 9 Pack Contents – PM2 SHCVO C 1. Concealing plate x2 2. Valve body x1 3. Handles x2 4. Spline adaptors x2 5. Valve body fixings x2/2 6. Inserts x2 7. Flow regulators x2 8. Filter washers x2 9. Wall outlet x1 10.
- Page 10 Pack Contents – RS SHCVO C 1. Concealing plate x1 2. Valve body x1 3. Handles x2 4. Spline adaptors x2 5. Valve body fixings x2/2 6. Inserts x2 7. Flow regulators x2 8. Filter washers x2 9. Wall outlet x1 10.
- Page 11 Pack Contents – DSC SHCVO C 1. Concealing plate x2 2. Valve body x1 3. Handles x2 4. Spline adaptors x2 5. Valve body fixings x2/2 6. Inserts x2 7. Flow regulators x2 8. Filter washers x2 9. Wall outlet x1 10.
- Page 12 Pack Contents – DSC SHCVO C 1. Valve body x1 2. Shrouds x2 3. Concealing plate x1 4. Handles x2 5. Valve body fixings x2/2 6. Inserts x2 7. Flow regulators x2 8. Filter washers x2 9. Wall outlet x1 10.
-
Page 13: Prior To Installation
Prior to Installation Flow Regulators This shower valve is supplied with a 5 and 7 litre per minute flow Filter regulator loose in the box which Washer must be fitted if the shower valve is installed in conjunction with an instantaneous water heater / combination boiler. -
Page 14: Installation
Installation – Shower Valve This shower valve is designed for Important: Water supplies to the installations where a recessed valve is mixer must be with hot on the left already installed in the wall cavity and cold on the right when and is to be replaced, or for new viewed from the front. -
Page 15: Shower Valve
Installation – Shower Valve 4. Fit concealing plate Note: The concealing plate can be used as a template by drawing around the plate and measuring in by 10mm to give sufficient clearance. Run a bead of waterproof silicon sealant around the inner edge of the concealing plate. -
Page 16: Wall Outlet
Installation – Wall Outlet Fitting the Wall Outlet There are two methods of fixing Backnut the wall outlet depending on the type of wall: a: With rear access once wall Rubber seal finished Fit the rubber washer to Washer the back of the wall outlet, place the assembly through a 25-30mm hole in the wall and secure Wall... - Page 17 Installation – Shower Kit The shower kit is only supplied with Note: If replacing an existing riser AR3 SHCMT C rail, check to see if the existing holes can be reused or covered by the new 1. Mark the position wall Position the assembled riser rail on the brackets.
-
Page 18: Shower Kit
Installation – Shower Kit Insert riser rail Insert the plastic bracket insert as shown into the wall bracket and slide the riser rail down through the bottom wall bracket Bracket ensuring the two holes in the riser are on the Insert Bottom wall bracket... -
Page 19: Operating The Shower
Operating the Shower 1. On / off control Turn the handle anti-clockwise to turn on and increase the flow of water. Turn the handle clockwise to turn off the flow of water. 2. Temperature control Adjustable temperature control. Turn the handle clockwise for a cooler temperature. -
Page 20: Maintenance
Thermostat Important: Take note of the 4.Grease the seals with a silicon grease position of the plastic stop and supplied by Bristan (part number: SP- handle – They must be refitted in the 495- 0002) and carefully refit. same position 5.Refit the temperature stop and... -
Page 21: Adjusting The Temperature
Adjusting the Temperature Adjusting the Temperature temperature of the water with a The shower valve has been factory set thermometer. If the temperature is to 42ºC with equal (balanced) hot and not correct, re-calibrate the shower cold water supply pressures, with the valve: hot water supply at 65ºC. -
Page 22: Troubleshooting
Troubleshooting Symptom Cause Remedy No flow or low Check showerhead, hose and Clean as necessary, refer to flow rate and filters for any blockage. Maintenance section (page / or varying 20). temperatures. Partially closed stop or service Open stop or service valve. valve water supply... - Page 23 Troubleshooting Symptom Cause Remedy Water This is normal for a short Adjust angle of showerhead leaking from time after turning off. in holder as necessary to showerhead. vary draining time. Shower cartridge failing Remove shower cartridge to close fully, possibly and check.
-
Page 24: Notes
Notes Please use this space to add any notes you or your installer may have regarding the plumbing system / installation of this product. Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors. - Page 25 Notes Please use this space to add any notes you or your installer may have regarding the plumbing system / installation of this product. Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
- Page 26 Notes Please use this space to add any notes you or your installer may have regarding the plumbing system / installation of this product. Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
- Page 27 Notes Please use this space to add any notes you or your installer may have regarding the plumbing system / installation of this product. Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
- Page 28 Telephone: 0330 026 6273 Email: enquire@bristan.com At Bristan, we want to make things as easy as possible for our customers. That’s why we offer solid guarantees on all our products, effective from the date of purchase, to give you peace of mind.
