- Page 1 Installation Instructions and User Guide Temperature Stabilised Thermostatic Mixing Valve Models Covered: MT753CP, MT753CP-ISO Please keep this booklet for future reference. Installer, when you have read these instructions please ensure you leave them with the user.
-
Page 2: Table Of Contents
Contents Welcome to your new Bristan Mixing Valve All products manufactured and supplied by Bristan are safe provided they are installed, used correctly and receive regular maintenance in accordance with these instructions. Isolation valves must be fitted to the inlet water supplies to ensure ease of future maintenance. -
Page 3: Specification
The sensitive wax capsule will shut down the valve if the hot or scan the QR Code or cold water supply fails, provided that there is at least a 10°C visit www.bristan.com difference between the mixed water temperature and the and search for your product. -
Page 4: Installation
4. Please refer to the TMV guide in order to test and commission the mixing If you have purchased MT753CP, we valve. advise installing insolation valves as close as its practical to the mixing valve for ease of maintenance. -
Page 5: General Cleaning
Head Assembly Thermostat Element Clamp Ring (0370) Return Spring BS029 O-Ring * 22mm Isolating Adaptor Assembly for MT753CP-ISO General Cleaning Bristan products are made from premium materials, with hand polishing and electroplated finishes. Your shower kit should be regularly cleaned with warm water, a mild pH-neutral liquid soap, and polished with a soft cloth. -
Page 6: Maintenance
Maintenance Temperature Adjustment This valve is pre-set to a maximum outlet temperature of 43°C. It can be adjusted to have a maximum temperature between 30°C - 55°C IMPORTANT: To comply with the TMV scheme, this valve cannot have a maximum outlet temperature of 44°C. If set higher, it will no longer comply with the TMV scheme. - Page 7 PTFE Seat cover (17). 22mm Copper Olive 22mm Compression Nut Note: If you have purchased the Brass Nut MT753CP-ISO, simply turn the screws Actuating Stem in the isolation assemblies (4G) to isolate the water supplies. O-Ring Connecting Nut 2. Unscrew the head assembly (20) from the body (12) using a suitable spanner.
- Page 8 Email: enquire@bristan.com A Masco Company At Bristan, we want to make things as easy as possible for our customers. That’s why we offer solid guarantees on all our products, effective from the date of purchase, to give you peace of mind.
