DIRECT VENT GAS INSERT (DVI-32)
INSTRUCTIONS
SAVE THESE INSTRUCTIONS
WARNING
personal injury or loss of life.
FOR YOUR SAFETY
WHAT TO DO IF YOU SMELL GAS
WARNING
PRIOR TO FIRST FIRE:
Part #250-3692 / #842-2620
(Revised 11/00)
www.aladdinhearth.com
aladdin@aladdinhearth.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVI-32 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Quadra-Fire DVI-32

  • Page 1 North America’s Best DIRECT VENT GAS INSERT (DVI-32) INSTALLATION, OPERATION, VENTING AND MAINTENANCE INSTRUCTIONS f i r e - p a r t s . c o m SAVE THESE INSTRUCTIONS WARNING If the information in this manual is not followed exactly a fire or explosion may result, causing property damage, personal injury or loss of life.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS PAGE Safety label ..........................3 Safety notices ..........................4 Specifications ..........................5 Gas line connection ........................5 Pressure testing ........................... 5 Dimensions ..........................6 Listings ............................7 High altitiude operation ........................ 7 Clearances to combustibles ......................7 Door installation ...........................
  • Page 3: Safety Label

    Report #061-S-16-5 1445 North HIghway October 1999 Colville, WA 99114 ANSI Z21.88a-1998 CSA 22.33a-M98 and CAN1 2.17-M91 VENTED GAS FIREPLACE HEATER MODEL: DVI-32 NG SERIAL NO. DVI-32 LP DVI-32 DVI-32 For use with Natural Gas For use with Propane †0-2000' †0-2000'...
  • Page 4: Safety Notices

    SAFETY NOTICES This appliance should only be installed by a qualified installer. It is approved for installation in a bedroom. The appliance must be electrically grounded in accordance with local codes, or the latest edition of the National Electric Code. If no local codes exist, this appliance should be installed following the current codes: CAN/CGA-B149.1 ................
  • Page 5: Specifications

    SPECIFICATIONS Manifold pressure 3.5” WC 10.0” WC Minimum inlet gas supply pressure 4.5” WC 11 0” WC Maximum inlet gas supply pressure 7.0” WC 14.0” WC BTU input rating (high) 32,000 32,000 BTU output rating (high)* 26,800 27,808 BTU input rating (low) 20,000 25,000 BTU output rating (low)*...
  • Page 6: Dimensions

    DIMENSIONS 30" (762mm) 29" (737mm) f i r e - p a r t s . c o m 23 15/16" (680mm) 12" (305mm) 7 1/2" (190mm) 14 1/2" (368mm) 13 13/16" (351mm) 30" (762mm) 10 9/16" (268mm) 11/16" (18mm) 250-3692 (11/2000) DVi32 Gas Insert...
  • Page 7: Listings

    LISTINGS The Quadra-Fire DVI-32 is listed to ANSI Z21.88a-1998, CSA 22.33a-M98 and CAN1 2.17-M91NFPA-70 by OMNI-Test Laboratories, Inc., Beaverton, Oregon. HIGH ALTITUDE OPERATION In Canada, this unit is approved from 0 to 4500 feet above sea level. Installation of this appliance at altitudes above 4500 feet are subject to field test of the individual installation and approval by the local authority having jurisdiction.
  • Page 8: Door Installation

    Figure 1 Figure 2 The DVI-32 is shipped from the factory with the door installed. To remove the door: f i r e - p a r t s . c o m 1. Turn eye bolts on each side of door, one-quarter turn to allow the door to slide forward.
  • Page 9: Thermostat Installation

    THERMOSTAT INSTALLATION If desired, a thermostat may be installed to regulate the Quadra-Fire DVI-32. It is important to use a thermostat designed for millivolt operation. Do not connect this appliance to a thermostat serving any other appliance. RECOMMENDED MAXIMUM LEAD...
  • Page 10: Venting Instructions

    DO NOT USE FIELD-FABRICATED VENTING COMPONENTS. The Quadra-Fire DVI-32 is approved to be vertically terminated in a masonry fireplace or a zero clearance fireplace with Simpson Dura-Vent GS series and flex pipe. Only Simpson Dura-Vent components labeled and listed in this section may be used.
  • Page 11: Venting Parts List

    Decorative brass and chrome trim kits are available for ceiling support boxes. The following components have been approved for use with the Quadra-Fire DVI-32: Number Description 3”...
  • Page 12: Planning Your Installation

    It is very important to maintain a balance between the com- bustion air intake and the flue gas exhaust venting system. MASONRY INSTALLATION The DVI-32 must be vented vertically, using Simpson Dura- Vent direct vent systems through a masonry fireplace or metal zero-clearance fireplace or can be installed using Simpson Dura-Vent GS series pipe in conjunction with Quadra-Fire zero clearance can.
  • Page 13 VERTICAL TERMINATIONS, CONT. USING GS SERIES PIPE (cont.) FIG. 2 Step 2. Set the gas appliance in its desired location. Drop a plum bob down from the ceiling to the position of the appliance flue exit, and mark the location where the vent will penetrate the ceiling.
  • Page 14 VERTICAL TERMINATIONS (cont.) USING GS SERIES PIPE (cont.) Shingles overlap top edge Step 6. Slip the flashing over the pipe section(s) of flashing. protruding through the roof. Secure the base of the flashing to the roof with roofing nails. Insure the roofing material overlaps the top edge of the flashing (Figure 4).
  • Page 15: Installing Into An Existing Masonry Or Factory-Built Metal Chimney

    VERTICAL TERMINATIONS (cont.) USING GS SERIES PIPE (cont.) CEILING FIRESTOP Step 8. Twist-lock the vent cap and seal. NAILS NOTE: For multi-story vertical installations, a ceiling FIG. 6 firestop (SDV part #963) is required at the second floor, and any subsequent floors (Figure 6). The opening should be framed to 10”...
  • Page 16 ONLY. IT IS NOT APPROVED FOR INSTALLATIONS IN CANADA. The DVI-32 has been tested using the chimney for the outside air source, but only under these conditions: 1. Do not use the co-axial to co-linear adaptor when using a single exhaust liner and the chimney as the outside air source.
  • Page 17: Lighting Instructions

    FFOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot that must be lit manually. When lighting the pilot, follow these instructions exactly B.
  • Page 18: First Fire

    FIRST FIRE MAINTENANCE CLEANING AND INSPECTION NOTE: Never operate this appliance with the door open. NOTE: No electrical power supply is required for the gas At least once yearly, preferably before the heating season, control to operate. Standing pilot allows the valve have the insert and venting system cleaned and inspected to operate with manual switch or millivolt by a qualified service person.
  • Page 19: Troubleshooting

    TROUBLESHOOTING ACCESSORIES Pilot won’t light These may be ordered through your Quadra-Fire dealer. Make sure valve setting is in the pilot position. Check for spark at igniter. 812-2880 Thermostat, manual If no spark: 811-0520 Thermostat, electronic set back Check the wiring between the piezo and 841-0320 Remote control the igniter.
  • Page 20: Warranty

    Aladdin Hearth Products. This new Quadra-Fire product must be installed by a competent, authorized service contractor. It must be installed and operated at all times in accordance with the Installation, Operation and Maintenance Instructions in this manual, as well as any applicable local and national codes.
