Digital VTH
(Version 4.3)
Quick Start Guide
V1.0.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Digital VTH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dahua Digital VTH

Summary of Contents for Dahua Digital VTH

  • Page 1 Digital VTH (Version 4.3) Quick Start Guide V1.0.0...

  • Page 2: Cybersecurity Recommendations

    Cybersecurity Recommendations Mandatory actions to be taken towards cybersecurity 1. Change Passwords and Use Strong Passwords: The number one reason systems get “hacked” is due to having weak or default passwords. It is recommended to change default passwords immediately and choose a strong password whenever possible.

  • Page 3: Foreword

    Foreword General This document mainly introduces structure, installation process, debugging and verification process of digital VTH products. Device Upgrade Please don’t cut off power supply during device upgrade. Power supply can be cut off only after the device has completed upgrade and has rebooted.
  • Page 4 official website. If there is inconsistency between paper User's Manual and the electronic version, the electronic version shall prevail. All the designs and software are subject to change without prior written notice. The product  updates might cause some differences between the actual product and the Guide. Please contact the customer service for the latest program and supplementary documentation.

  • Page 5: Important Safeguards And Warnings

    Important Safeguards and Warnings The following description is the correct application method of the device. Please read the Guide carefully before use, in order to prevent danger and property loss. Strictly conform to the Guide during application and keep it properly after reading. Operating Requirement Please don’t place and install the device in an area exposed to direct sunlight or near heat ...

  • Page 6: Table Of Contents

    Table of Contents Cybersecurity Recommendations ......................I Foreword ..............................II Important Safeguards and Warnings ....................IV 1 Product Structure ..........................1 1.1 Front Panel ............................ 1 1.2 Rear Panel Port ..........................2 1.2.1 VTH5221 Series /VTH5241 Series ..................2 1.2.2 VTH5221E-H/VTH5221EW-H .................... 2 1.2.3 VTH15XX-S2 Series Type B/Type CH &...

  • Page 7: Product Structure

    Product Structure Front Panel Different models of devices may have different front panel dimensions and key types, but keys or indicators with the same silkscreen or icon have the same function. Please refer to Table 1-1 for details. Icon Name Description Silkscreen Press this key to call the Call Center in case of emergency.

  • Page 8: Rear Panel Port

    1.2.3 VTH15XX-S2 Series Type B/Type CH & VTH15XX Series Type B/Type CH In VTH15XX-S2 type CH series, different types of digital VTH have different port positions, but the same port provides the same function. Taking VTH1550CH-S2 as an example, specific functions of ports are introduced, as shown in Figure 1-3.
  • Page 9 Figure 1-4. Figure 1-4 In VTH15XX type CH series, different types of digital VTH have different port positions, but the same port provides the same function. Taking VTH1550CH as an example, specific functions of ports are introduced, as shown in Figure 1-5.

  • Page 10: Vth5222Ch/Vth5222Chw-2

    Figure 1-6 1.2.4 VTH5222CH/VTH5222CHW-2 Except different numbers of 2-wire port, VTH5222CH and VTH5222CHW-2 are the same in other aspects. VTH5222CH has 1 group of 2-wire port, while VTH1550CHW-2 has 3 groups of 2-wire port. VTH5222CH is shown in Figure 1-7. Figure 1-7 1.2.5 VTH1660CH Its ports are described in Figure 1-8.

  • Page 11: Vth2421Fb/Vth2421Fs

    Figure 1-9 1.2.7 VTH2421FB/VTH2421FS Its ports are described in Figure 1-9. Figure 1-9 错误!使用“开始”选项卡将 Heading 1,l1,H1,Title1,Normal + Font: Helvetica,Bold,Space Before 12 pt,Not Bold,Heading One,h1,Head1,Head,1,Numbered,nu,Level 1 Head,1st level,Section He ad,Sec1,h11,1st level1,h12,1st level2,h13,1st level3,h14,1st level4,h15,1st level5,h16,h17 5...

  • Page 12: Installation And Debugging

    Installation and Debugging Installation Don’t install VTH in bad environment, such as condensation, high temperature, stained,  dusty, chemically corrosive and direct sunshine environment. In case of abnormality after power on, please pull out network cable and cut off power ...

  • Page 13: Installation With 86 Box

    2.1.2 Installation with 86 Box Install the device with 86 box, which is suitable for all types of devices. Take “VTH1560B/BW” for example. Embed 86 box into a wall at a proper height. Fix installation bracket onto 86 box with screws. Put the device into installation bracket from top down.

  • Page 14: Debugging

    Figure 2-3 Debugging Carry out debugging to ensure that the device can realize basic network access, call and monitoring functions after installation. Before debugging, please check whether the following work has been completed. Check whether there is short circuit or open circuit. Power on the device only after the ...
  • Page 15 Figure 2-4 According to interface prompt, enter “Password” and “Confirm Password”, and click “Next”. Select “Email” and enter your Email address. This Email address is used to reset the password, so it is recommended that it should be set. Enter default address in the browser to login WEB interface. Default username is admin.
  • Page 16 Figure 2-6 Select system type as “TCP/IP”. Click “OK” to save the settings. Reboot the device manually, or wait for auto reboot and put the settings into effect. Login WEB interface again; select “Network Setting > SIP Server”. The system displays “SIP Server” interface, as shown in Figure 2-7. Figure 2-7 Select server type.
  • Page 17 Figure 2-8 This VTO works as SIP server.  Select “SIP Server Enable”, and click “OK” to save config. The VTO reboots automatically. Another VTO or platform works as SIP server.  Set parameters by reference to Table 2-1 and click “OK”. The VTO reboots automatically.
  • Page 18 Figure 2-9 Click “Add”, set outdoor station parameters by reference to Table 2-2 and click “OK”. Repeat this step to add other outdoor stations in the group. Parameter Description VTO No. VTO number. Signaling interactive use in SIP system. Adopt default Register Password value.

  • Page 19: Vth Settings

    Parameter Description Set VTH room number. VTH room number consists of 1～6 numbers, letters, or  their combinations.. It shall be consistent with room number configured at VTH. Room No. When there are master VTH and extensions, to realize  group call function, master VTH short no.
  • Page 20 Figure 2-11 Enter “Password”, “Confirm Pwd” and “Email”. Press [OK]. Press [Setting] for more than 6 seconds, enter the password set during initialization, and click [OK]. Click [Network]. The system displays “Network” interface, as shown in Figure 2-12 or Figure 2-13. IP addresses of VTH and VTO shall be in the same network segment.
  • Page 21 Enter “Local IP”, “Subnet Mask” and “Gateway”, press [OK]. Or press to enable DHCP function and obtain IP info automatically. If the device has WLAN function, please click “WLAN” tab to set it. WLAN  Press to enable Wi-Fi function. The system displays available Wi-Fi list, as shown in Figure 2-14.
  • Page 22 Figure 2-15 Be used as a master VTH.  Enter “Room No.” (such as 9901 or 101#0) and press “OK” to save. “Room no.” shall be the same with “VTH Short No.”, which is set when adding  VTH at WEB interface. Otherwise, it will fail to connect VTO. In case of extension VTH, room no.
  • Page 23 Figure 2-16 Set parameters of SIP server by reference to Table 2-4. Parameter Description When the platform works as SIP server, server IP is IP address of the platform. Server IP When VTO works as SIP server, server IP is IP address of the VTO.

  • Page 24: Debugging Verification

    Figure 2-17 Add VTO or fence station. Add main VTO.  Enter “Main VTO Name”, “VTO IP Address”, “User Name” and “Password”. Switch the “Enable Status” to be “User Name” and “Password” shall be consistent with WEB login user name and password of VTO.

  • Page 25: Vth Monitors Vto

    Figure 2-18 2.3.2 VTH Monitors VTO VTH is able to monitor VTO, fence station or IPC. Take “VTO” for example. Select “Monitor > Door”, as shown in Figure 2-19. Select the VTO to enter monitoring image, as shown in Figure 2-20. The following figure means that SD card has been inserted into VTH.
  • Page 26 Figure 2-19 Figure 2-20 错误!使用“开始”选项卡将 Heading 1,l1,H1,Title1,Normal + Font: Helvetica,Bold,Space Before 12 pt,Not Bold,Heading One,h1,Head1,Head,1,Numbered,nu,Level 1 Head,1st level,Section He ad,Sec1,h11,1st level1,h12,1st level2,h13,1st level3,h14,1st level4,h15,1st level5,h16,h17 20...
