DirecTV SWiM Installation Diagrams page 6

Distance between
the Power Inserter
and the SWiM
switch can not
exceed 150 ft
Video
Video
Out to TV Off Air In
Satellite In Ports
HD
S-Video
DVR
SWM-1 2
Video
Video
Out to TV
Off Air In
Satellite In Ports
SWM 1
Phone
120V
Phone
S-Video
120V
Internal
Wall Plates
dB Loss
Compone nt Q TY Per
F- Conne ctors 6
F-81 Barrels 2
SWiM SWS 4 1 11.0
Fe et of Cable 150
Highe st Fre quency
1178MHz 7.01
use d (see chart)
Path # 1 Total Loss =
O DU dBm =
Net dBm at rece iver
All Outdoor F-Connectors
Weather Seal identifier must be tightened to no less
than 30 inch lbs to include
LNB's
External Wall
Splitters can be installed exterior of the
residence, however port termination and
Terminator
weather sealing rules still apply
on unused
ports
SWiM Integrated LNB Installation
Ne t Loss
KaKu -
0.5 3
HD DVR SWiM compatible IRD
1.0 2
Single tuner SWiM compatible IRD
11
4 way single port DC power passing
splitter rated from 2-2150MHz
BBC's are not required in this scenario
10.5
26.5
-30
-56.5
Black Ground Wire
Indicates # 17ga
CCS Bond
Terminator
on unused
ports
Service
Panel
Green Bonding
Wire Indicates #
10ga Solid Copper
