DirecTV SWiM Installation Diagrams page 19

95°
LNB
72.5°
LNB
Weather
Cap on
Unused
Ports
Distance between
the Power Inserter
and the SWiM
switch can not
exceed 150 ft
Video
Video
Out to TV Off Air In
Satellite In
S-Video
SWM-
1
Video
Video
Out to TV Off Air In
Satellite In Ports HD
S-Video
DVR
SWM-
2
1
Phone
120V
Phone
120V
Internal
Wall Plates
Weather Seal identifier
Weather
Cap on
Unused
Ports
8 Channel SWiM
18v 13v
18v/22KHz 13v/22KHz
Sat 99°/ Sat 99°/
Sat 103°/110°/119°
101° 101°
External Wall
Bonding
"The following grounding diagrams illustrate only a few examples of ways to bond a DIRECTV system
and may not meet bonding requirements in every municipality within the United States. It is the
responsibility of the installer/technician performing the installation to know and follow all local, state
and federal grounding regulations within the area he or she is working."
SWiM 8 Channel Switch Installation
KaKu - 95° - 72.5°
Single tuner SWiM compatible IRD
HD DVR SWiM compatible IRD
BBC's are not required in this scenario
Black or Blue Ground Wire
Indicates # 17ga CCS Bond
Flex Flex
Port
Port
1 2
All Outdoor F-Connectors
must be tightened to no less
than 30 inch lbs to include
LNB's
Service
Panel
Green Bonding
Wire Indicates #
10ga Solid Copper
