DirecTV SWiM Installation Diagrams page 21

95°
LNB
72.5°
LNB
Weather
Cap on
Unused
Ports
Distance between
the Power Inserter
and the SWiM
switch can not
exceed 150 ft
Video
Video
Out to TV
Off Air In
Satellite In Ports
HD
S-Video
DVR
SWM-1 2
Video
Video
Out to TV Off Air In
Satellite In Ports R-15
DVR
1 2
Phone
120V
Phone
S-Video
120V
Internal
Wall Plates
Weather Seal identifier
8 Channel SWiM
18v 13v
18v/22KHz 13v/22KHz
Sat 99°/ Sat 99°/
Sat 103°/110°/119°
101° 101°
To an additional legacy single tuner IRD
Terminator
on unused
ports
External Wall
SWiM 8 Channel Switch Installation
KaKu - 95° - 72.5°
HD DVR SWiM compatible IRD
R-15 DVR IRD using SWiM Legacy ports
4 way single port DC power passing
splitter rated from 2-2150MHz
BBC's are not required in this scenario
Black or Blue Ground Wire
Indicates # 17ga CCS Bond
Terminator
Flex
Flex
Port
Port
2
1
Service
Panel
Green Bonding
Wire Indicates #
10ga Solid Copper
All Outdoor F-Connectors
must be tightened to no less
than 30 inch lbs to include
LNB's
