DirecTV SWiM Installation Diagrams page 11

95°
LNB
Distance between
the Power Inserter
and the SWiM
switch can not
exceed 150 ft
Video
Video
Out to TV Off Air In
Satellite In
S-Video
SWM-
1
Video
Video
Out to TV Off Air In
Satellite In Ports HD
S-Video
DVR
SWM-
2
1
Weather
Cap on
Unused
Ports
Phone
120V
Phone
120V
Internal
Wall Plates
Weather Seal identifier
Weather
Cap on
Unused
Ports
5 Channel SWiM
18v 13v
18v/22KHz 13v/22KHz
Sat 99°/ Sat 99°/
Sat 103°/110°/119°
101° 101°
External Wall
Splitters can be installed exterior of the
residence, however port termination and
Terminator
on unused
ports
SWiM 5 Channel Switch Installation
KaKu - 95°
Single tuner SWiM compatible IRD
HD DVR SWiM compatible IRD
4 way single port DC power passing
splitter rated from 2-2150MHz
BBC's are not required in this scenario
Black or Blue Ground
Wire Indicates # 17ga CCS
Terminator
Flex Flex
Port
Port
1 2
Weather
Cap on
Unused
Ports
All Outdoor F-Connectors
must be tightened to no less
than 30 inch lbs to include
LNB's
weather sealing rules still apply
Bond
Service
Panel
Green Bonding
Wire Indicates #
10ga Solid Copper
