DirecTV SWiM Installation Diagrams page 24

Distance between
the Power Inserter
and the SWiM
switch can not
exceed 150 ft
Video
Video
Out to TV
Off Air In
Satellite In Ports HD
S-Video
DVR
SWM-1 2
Video
Video
Out to TV Off Air In
Satellite In Ports R-15
DVR
1
2
Weather
Cap on
Unused
Ports
Phone
120V
Phone
Internal
Wall Plates
S-Video
120V
Weather Seal identifier
8 Channel SWiM
18v 13v
18v/22KHz 13v/22KHz
Sat 99°/ Sat 99°/
Sat 103°/110°/119°
101° 101°
Terminator
on unused
ports
External Wall
Splitters can be installed exterior of the
residence, however port termination and
SWiM 8 Channel Switch Installation
KaKu -
HD DVR SWiM compatible IRD
R-15 DVR IRD using SWiM Legacy ports
4 way single port DC power passing
splitter rated from 2-2150MHz
BBC's are not required in this scenario
All Outdoor F-Connectors
Off-Air HD Antenna
must be tightened to no less
than 30 inch lbs to include
LNB's
Terminator
Flex
Flex
Port Port
2
1
weather sealing rules still apply
Black Ground Wire
Indicates # 17ga
CCS Bond
Service
Panel
Green Bonding
Wire Indicates #
10ga Solid Copper
