Summary of Contents for Insight Vision Xpress
- Page 1 An Alliance Technology Company An Alliance Technology Company 1 of 14 Xpress User Manual 600 Dekora Woods Blvd. Saukville, WI 53080 Toll Free: 800-488-8177 Local: 262-268-9330 Fax: 262-268-9952...
- Page 2 An Alliance Technology Company An Alliance Technology Company 2 of 14 TABLE OF CONTENTS Warranty……………………………….page 3 Command Module……………………page 6 BaseFrame…………………………….page 11 Camera…………………….…………...page 13 600 Dekora Woods Blvd. Saukville, WI 53080 Toll Free: 800-488-8177 Local: 262-268-9330 Fax: 262-268-9952...
- Page 3 An Alliance Technology Company An Alliance Technology Company 3 of 14 1 YEAR WARRANTY Alliance Technology, LLC warrants to the first purchaser that should any of its products prove to be defective in material or workmanship in normal use, within one (1) year from the date of delivery, Alliance Technology, LLC will, at its exclusive option, repair, replace or exchange the product or any of its parts.
- Page 4 Insight-Vision will not allow warranty coverage for these items if these procedures are not followed. Digital Xpress Memory Card Recorder: Due to the adverse conditions that the DX experiences during use, Insight Vision strongly recommends that the cleaning procedure described below be performed for every 5 or 6 hours of use.
- Page 5 An Alliance Technology Company An Alliance Technology Company 5 of 14 Camera Head: The camera head area, especially around the front light window, is an area that is subject to wear and tear. Insight-Vision has provided a small and large protective skid that MUST be used at all times.
- Page 6 6 of 14 Xpress Command Module The Xpress Command Module allows real time viewing of a camera image on an LCD flat panel screen. The advanced features of the Xpress Command Module provide recording and playback of camera images, audio commentary, and text writer capabilities using optional external components.
- Page 7 7 of 14 SYSTEM OPERATION Open the LCD Flat Panel Lid on the Xpress Command Module and position the screen for best viewing angle. The Lid is used to protect the operator control area when not in use. The Operator Control Buttons are prominently featured and are easily accessible on the large water resistant keypad.
- Page 8 YELLOW LED is illuminated or flashing with an external power source connected. A flashing YELLOW LED indicates the external power source is low. The advanced Xpress Command Module may continue operating indefinitely in this state as long as the power level does not decrease further.
- Page 9 An Alliance Technology Company An Alliance Technology Company 9 of 14 Immediately disconnect the Command Module for the external power source. Reconnect the unit to an adequate 13.8-15VDC or 110/220VAC power source. The yellow DC low LED is utilized as a short circuit indicator. When system power levels are nominal, a slow flash is used to indicate that a short has been detected.
- Page 10 An Alliance Technology Company An Alliance Technology Company 10 of 14 Due to the advanced auto-iris feature, we recommend setting the light intensity controls to maximum. If the LED’s are not illuminated or are otherwise malfunctioning, please reference the “USER TROUBLESHOOTING GUIDE” in this manual. Remove the camera from basket and insert into the pipe to be inspected.
- Page 11 Xpress command modules. Stiff Rod (A) The letter A following the rod length indicator designates the Insight Vision rigid push rod. Example: 200A = 200’ of stiff rod. This push rod is .475” in diameter and has been specifically designed for longer pushing distances in 2”-12”...
- Page 12 An Alliance Technology Company An Alliance Technology Company 12 of 14 Debris Bag This optional item comes in two sizes, one for each size of base frame reels. It is intended to minimize drippings while working indoors. It is easily removable for cleaning. 600 Dekora Woods Blvd.
- Page 13 The Sonde is not built into the camera. This camera is intended for operation in pipes 2-12” I.D. This camera will function with any of our Xpress command modules as well as our Silver Bullet or Universal Jetcam systems. Diameter is 1.30”...
- Page 14 An Alliance Technology Company An Alliance Technology Company 14 of 14 Installation and removal of skids. The skid is a two-piece device that must be unscrewed for installation. Slide the rear half over the pushrod and slid forward to the rear of the camera. Slide the front half over the camera to meet the rear half.
