Insight Vision IV2 Owner's Manual

Hide thumbs Also See for IV2:

Advertisement

Quick Links

Download this manual
0

Advertisement

loading
Need help?

Need help?

Do you have a question about the IV2 and is the answer not in the manual?

Questions and answers

Related Manuals for Insight Vision IV2

Summary of Contents for Insight Vision IV2

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Regulatory Statement ............Tablet Hardware Software Warranty ........General Warranty ..............General Overview ..............General Operation ..............IV2 Tablet App ..............Base Frame ................. Camera Head ............... Troubleshooting Guide ............Technical Specifications ............ Contact Us ................
  • Page 4 To reduce the risk of injury, user must read operator’s manual. Wear eye protection and observe all  applicable safety precautions. NOTICE: Use only the power supply recommended by Insight Vision. A non-approved 12 volt DC power supply may  cause damage or render equipment non-operable. WARNING: To reduce the risk of injury and prevent equipment damage.
  • Page 5 And that any other software or applications that affect or limit the use of the system is not the responsibility of Insight Vision. This may be due to the installation of the latest hardware or software or other applications.

  • Page 6: General Warranty

    Insight Vision warrants to the original purchaser that should any of its products prove to be defective in material or workmanship in normal use, within one (1) year from the date of delivery, Insight Vision will, at its exclusive option, repair, replace or exchange the product or any of its parts.

  • Page 7: General Overview

    IV2 TABLET COMMAND MODULE: The IV2 TABLET incorporates a USB port. If water, dirt or dust become present in this connector due to extreme conditions in the field, owners/operators will be responsible for the cleaning of the connector/port area using a Q-tip or other non-abrasive cleaning tool to remove the debris before inserting a memory stick or USB cable.

  • Page 8: General Operation

    How to Properly Push Cable Through Pipe and Retrieve: Your IV2 TABLET reel is equipped with a cable guide to allow for easy spooling and unspooling of the push rod. Failure to use the cable guide may cause reduced performance of the system.
  • Page 9 For advanced location of the camera head, the IV2 TABLET reel is equipped with an always on 512Hz sonde which can be located with a locator.

  • Page 10: Iv2 Tablet App

    IV2 TABLET Powering Up the System Insert Battery or connect AC/DC power to the back of IV2 TABLET module. Press the Power Button on the back of the IV2 TABLET. The system will power on once the power button is pressed.
  • Page 11 IV2 Tablet App Control 1. Expand/ Minimize Menu Window 2. Record/ Pause 3. Stop Recording 4. Snapshot 5. Reset Distance Counter 6. Display User Information 7. Display Project Information 8. Display Additional Notes 9. Display Additional Message 1 10. Display Additional Message 2 11.
  • Page 12 On-Screen Display (OSD): Expand OSD Window Press the Button to expand the On-Screen  Display. Screen will now show full display (pic 2). Minimize OSD Window Press the Button to minimize the OSD to look  like pic 1. Pic 1 One Touch Video Recording Press the Button to start recording.
  • Page 13 On-Screen Display (OSD): User Information Enter user information into the correct field  Button will display entered User Information on  screen for 10 seconds (see below) Selecting “Clear User” erases all User Information  Note: The User Information will be auto saved until new changes are entered.
  • Page 14 On Screen Display (OSD): Notes Enter notes information, hitting enter will create new • line Button will display entered Notes on screen for 10 • seconds Simply click on, “Clear Notes” to quickly erase all • notes Notice: The notes will be auto saved until new changes are entered.
  • Page 15 On Screen Display (OSD): File Links To access recorded videos, press “Click to Open • Videos” and the video folder will open (see below) To access recorded pictures, press “Click to Open • Snapshots” and the snapshots folder will open Notice: Videos can be played back using system’s media player (Windows Media Player).

  • Page 16: Base Frame

    The Debris bag is intended to minimize drippings while working indoors. It is easily removable for cleaning. Battery (not included) The IV2 TABLET does not come with the M18-style battery but it is available online or at your local home improvement or hardware store.
  • Page 17 AC Power Adaptor The plug in for 110V to power up the system. DC Power Adapter The use the car power adapter to start up the system. Video Interconnect Cord The video inter-connect cord will need to be connected from the reel to the command module to display video.
  • Page 18 This camera is intended for operation in pipes 2-12” I.D. This camera will function with any of our IV2 TABLET command modules. The diameter of the camera head is 1.30”, fits best for 3” up to 12” pipes inspections. The Sonde is not built into the self-leveling camera.

  • Page 19: Camera Head

    The skid is one-piece device that affixes over the camera head. The skid is used to protect the integrity of the camera head and normal usage wear and tear. It is held down by three set screws. Use the Allen wrench provided by Insight Vision in the accessory bag to loosen the skids to slide out the camera head.

  • Page 20: Troubleshooting Guide

    3. What happens if I lose the LED lights on my camera head during an inspection? a. Verify that the LED lights are fully bright by pressing the lights “UP” button, on the front of your IV2 TABLET command module, a number of times.

  • Page 21: Technical Specifications

    Technical Specifications IV2 TABLET Tablet: Physical: 5" L x 14 ½” W x 11 ¼” H Display Pixel: 640x480 Data Storage: 56GB Internal Storage Operating System: Windows™ 10 Recording format: H.264 Image Capture: JPEG Counter: Displays on screen FT/M Controls:...
  • Page 22 We are an innovative manufacturer company that designs professional sewer inspection cameras. We focus on developing user-friendly video pipe inspection equipment. Our vision and enthusiasm inspire us to create new designs that satisfy your needs. INSIGHT VISION 600 Dekora Woods Blvd. Saukville, WI 53080 Phone: 1-800-488-8177 Fax: 1-262-268-9952 Service &...
  • Page 24 www.insightvisioncameras.com | Made in the USA Print Date: 09/18/2019...
