6
Mount the climate control panel and equalizer to
the sub-dash with (2) screws previously removed
in step #3.
8
Re-connect the battery terminal and test the unit for proper operation. Mount the head unit/kit
assembly to the sub-dash with (2) 7mm hex-head screws previously removed in step #1.
3
7
A
B
C
D
A) Strip wire ends back ½"
B) Twist ends together
C) Solder
D) Tape
Locate the factory wiring harness in the
dash. Metra recommends using the
proper mating adaptor and making
connections as shown. (Isolate and
individually tape off the ends of any
unused wires to prevent electrical short
circuit).
rev. 290601
KIT FEATURES
Shaft and
DIN unit
99-3103
provisions
Equalizer
INSTALLATION
provisions
INSTRUCTIONS
KIT COMPONENTS
APPLICATIONS
Radio Housing
CAR
SATURN
(All models) 1995-99...............................................1-2
Shaft
Supports
Equalizer
Brackets
TOOLS REQUIRED
Phillips screwdriver
Cutting tool
1-800-221-0932
File
© COPYRIGHT 2001 METRA ELECTRONICS CORPORATION
PAGE
www.metraonline.com
