Introduction
Product overview
This is the installation manual for TruVision 6MP and 12MP 360° camera models:
SKU
Description
TruVision 360° IP Dome, 6MP, Indoor, DWDR, 1.29 mm fisheye
lens, True D/N, 15m IR, Bi-directional audio (built-in mic &
TVF-5201
speaker), Alarm (alarm input and alarm output), SD/SDHC slot,
PoE + (802.3-at) /12 VDC, Gray
TruVision 360° IP Dome, 12MP, indoor, DWDR, 1.29 mm
fisheye lens, True D/N, 15m IR, bidirectional audio (built-in mic
TVF-5202
& speaker), Alarm (alarm input and alarm output), SD/SDHC
slot, PoE + (802.3-at) /12 VDC, Gray
TruVision 360° IP Dome, 6MP, Outdoor, DWDR, 1.29 mm
fisheye lens, True D/N, 15m IR, bidirectional audio (built-in mic
TVF-5203
& speaker), Alarm (alarm input and alarm output), SD/SDHC
slot, IP67, IK10, PoE + (802.3-at) /12 VDC, Gray
TruVision 360° IP Dome, 12MP, Outdoor, DWDR, 1.29 mm
fisheye lens, True D/N, 15m IR, bidirectional audio (built-in mic
TVF-5204
& speaker), Alarm (alarm input and alarm output), SD/SDHC
slot, IP67, IK10, PoE + (802.3-at) /12 VDC, Gray
Installation
This chapter provides information on how to install the cameras.
Warning: When the 360° camera is operating, the surface of the housing will be
hot to the touch. The heat buildup is due to the processing power that is required
to operate the camera.
Installation environment
When installing your product, consider these factors:
Electrical: Install electrical wiring carefully. It should be done by qualified
•
service personnel. Always use a proper PoE switch or a 12 VDC UL listed
Class 2 or CE certified power supply to power the camera. Do not overload
the power cord or adapter.
2
