Linkable tri-colour DMX laser effects
M
A
N
U
A
100mW Red + 150mW Violet / colour mixed to equal Pink
For the latest instruction manual updates and information on the entire Kam range visit:
www.kam.co.uk
Kam products are manufactured by: Lamba plc, Unit 1, Southfields Road, Dunstable, Bedfordshire, United Kingdom LU6 3EJ
Telephone: (+44) (0)1582 690600 • Fax: (+44) (0)1582 690400 • Email: mail@lambaplc.com • Web: www.lambaplc.com
If this product is ever no longer functional please take it to a recycling plant for environmentally friendly disposal.
Due to continuous product development, specifications and appearance are subject to change.
iLINK RVP
L
V
E
R
18 / 04 / 12
Plug & Play operation & built-in patterns
Linkable as a kit in Master/Slave mode
Auto, Sound-to-Light & DMX512 modes
10 channel DMX512 operation
LED function display
3 pin XLR DMX connection
Fan cooled operation
Key operated safety control
Safety mounting point
Adjustable hanging bracket
Tough metal chassis
© Copyright Lamba plc 2010. E&OE.
S
I
O
N
5
.
0
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for KAM iLINK RVP
Summary of Contents for KAM iLINK RVP
- Page 1 For the latest instruction manual updates and information on the entire Kam range visit: www.kam.co.uk Kam products are manufactured by: Lamba plc, Unit 1, Southfields Road, Dunstable, Bedfordshire, United Kingdom LU6 3EJ Telephone: (+44) (0)1582 690600 • Fax: (+44) (0)1582 690400 • Email: mail@lambaplc.com • Web: www.lambaplc.com If this product is ever no longer functional please take it to a recycling plant for environmentally friendly disposal.
- Page 2 Thank you for purchasing this KAM product, we are sure that it will serve you for many years to come. To optimise the performance of this product, please read these operating instructions carefully to familiarise yourself with the basic operations of this unit. After you have read the instructions, please retain them for future reference.
- Page 3 Panel NAME DESCRIPTION Power LED Indicates the fixture is switched on Music LED Synchronize to detected music signal The laser effect output aperture. NEVER LOOK INSIDE THE FIXTURE THROUGH THIS Laser Aperture APERTURE WHILE FIXTURE IS OPERATING. Power Switch Switch ON and OFF the fixture Fuse Holder Replace fuse with correct value if required Main Power Input...
- Page 4 Control & Function Regular breaks during operation are essential to maximize the life of this device as it is not designed for continual use. Do not switch the unit on and off in short time intervals. Always unplug the unit when it is not used for a longer time or before replacing the bulb or start servicing.
- Page 5 Sound activated mode sensitivity setting Press FUNC till to see S **. Press UP/DOWN to set microphone sensitivity. S 0 is no sound activation, from S1 to S9 is sound activated, S1 min S9 max. Press ENTER to confirm and save the setting. The sound sensitivity can be adjusted to determine how sensitive the laser is to sound.
-
Page 6: Value Function
DMX Protocol CHANNEL VALUE FUNCTION 000-029 AUTOMATIC SHOW with single RVP colour 030-059 AUTOMATIC SHOW with single VIOLET colour 060-089 AUTOMATIC SHOW with single RED colour 090-119 AUTOMATIC SHOW with PINK colour CH 1MODE 120-149 SOUND ACTIVATED SHOW with single RVP colour 150-179 SOUND ACTIVATED SHOW with single VIOLET colour 180-209... -
Page 7: Specifications
Pattern list in channel 2 PATTERNS PATTERNS PATTERNS PATTERNS 000-007 064-071 128-135 192-199 008-015 072-079 136-143 200-207 016-023 080-087 144-151 208-215 024-031 088-095 152-159 216-223 032-039 096-103 160-167 224-231 040-047 104-111 168-175 232-239 048-055 112-119 176-183 240-247 056-063 120-127 184-191 248-255 Specifications Mains Input...
