- Page 1 CAL. YT57, YT58 ® KINETIC E. S. U. (Electricity Storage Unit) Energy depletion forewarning function Instant-start function Time and date calendar (Cal. YT57) Time and day/date calendar (Cal. YT58) Rotating bezel (only for models with rotating bezel)
-
Page 2: Display And Crown
DISPLAY AND CROWN [ Cal. YT57 ] [ Cal. YT58 ] Hour hand Minute Hour Minute hand hand hand a b c a b c CROWN CROWN Second hand Date Second hand Day and date a: Normal position b: First click c: Second click... - Page 3 SCREW DOWN CROWN [for models with screw down crown] Unlocking the crown 1 Turn Crown counterclockwise until you no longer feel the threads turning. 2 Crown can be pulled out. Locking the crown 1 Push Crown back in to normal position. 2 Turn Crown clockwise while pressing it lightly until tight.
- Page 4 HOW TO CHARGE AND START THE WATCH 1 Swing the watch from side to side. * Swing rhythmically at a rate of twice a second. 2 Charge the KINETIC E. S. U. sufficiently. 3 Set the time/calendar and put on the watch.
- Page 5 Number of swings and power reserve POWER 1 day 12 hours 6 months RESERVE FULL NUMBER OF SWINGS 1 When the watch stops completely, a few swings will start the second hand moving at two-second intervals. 2 Swing the watch approximately 100 times. There will be about 12 hours of power reserve available.
- Page 6 Power reserve accumulated while you are walking 150 m 500 m Wearing the watch. Power reserve 12 hours 1 day The second hand starts moving at one-second intervals. The illustration provides only a general guideline of the relationship between the power reserve and the distance you walk.
- Page 7 FULL CHARGE OF THE KINETIC E. S. U. When the KINETIC E. S. U. is fully charged, the watch will keep operating for a maximum of about 6 months without recharging the KINETIC E. S. U. REMARKS ON THE KINETIC E. S. U. The electric energy generated while the watch is worn on your wrist is stored in the KINETIC E.S.U.
-
Page 8: Energy Depletion Forewarning Function
ENERGY DEPLETION FOREWARNING FUNCTION When the second hand starts moving at two-second intervals instead of the normal one-second intervals, the watch will run down in approximately 12 hours. In this case, swing the watch from side to side to charge the KINETIC E. S. U. sufficiently. - Page 9 TIME/CALENDAR SETTING [ Cal. YT57 ] Second hand CROWN 1 Pull out to first click and set the previous day’s date. 2 Pull out to second click when the second hand is at the 12 o’clock position. 3 Turn to set the desired date. 4 Turn to set the hands to the desired time.
- Page 10 [ Cal. YT58 ] Second hand CROWN 1 Pull out to first click and turn clockwise to set the previous day’s date. 2 Turn counterclockwise to set the previous day of the week. 3 Pull out to second click when the second hand is at the 12 o’clock position.
- Page 11 ROTATING BEZEL (for models with rotating bezel) The rotating bezel can show up to 60 minutes of elapsed time. 1 Turn the rotating bezel to align its “ ” mark with the minute hand. * For some models, the rotating bezel rotates only counter- clockwise.
-
Page 12: Notes On Operating The Watch
NOTES ON OPERATING THE WATCH HOW TO CHARGE AND START THE WATCH To charge the KINETIC E. S. U. efficiently, swing the watch from side to side, making an arc of about 20 cm. No additional benefit is obtained by swinging the watch more quickly or with greater vigor. When the watch is swung, the oscillating weight in the generating system rotates to drive the mechanism. - Page 13 INSTANT-START FUNCTION If the second hand starts moving at two-second intervals again soon after the watch is put on your wrist, swing it from side to side until the second hand moves at one-second intervals, and then, put it on your wrist again. TIME/CALENDAR SETTING For Cal.
-
Page 14: To Preserve The Quality Of Your Watch
If the watch becomes wet, we suggest that you Water resistance (10 bar/15 bar/20 bar)* have it checked by an AUTHORIZED PULSAR If “WATER RESISTANT 10 BAR”, DEALER or SERVICE CENTER. “WATER RESISTANT 15 BAR”... - Page 15 * Before using the water resistance 5, 10, 15 or 20 bar watch in water, be sure the crown is pushed in completely. Do not operate the crown when the watch is wet or in water. If used in sea water, rinse the watch in fresh water and dry it completely.
- Page 16 2 to 3 years. Have your watch 2 - 3 Years may cause damage. checked by an AUTHORIZED PULSAR DEALER or SERVICE CENTER to ensure that the case, crown, CHEMICALS gasket and crystal seal remain intact. Be careful not to expose the...
