TEMPLATE KIT / PARTS LIST

CIR-9030 [FOR CIR-3]
CIR-9040 [FOR CIR-4]
CIR-9050 [FOR CIR-5]
2
12
11
13*
1
ITEM QTY
1 1
2 1
3 1
4 4
5 1
6 4
7 4
8 4
9 8
10 1
11 1
12 1
13
2
10
9
PART NO.
BUG-2440
BUG-2915
BUG-9180-10
CIR-9031
CIR-9032
CON-1004
CON-1040
FAS-0257
FAS-2553
PAN-1009
PAN-1018
PAN-1033
--------------
8
DESCRIPTION
Base, Post (Block) - Order separately
Torchholder Assembly
1/8" (22 mm) rod, 10" (254 mm) Long
Spacer Leg
Aluminum Master Template Guide
(For CIR-3)
Alignment Bars (included with
Ring Gear Assembly)
Magnet Foot and Leg Assembly-Order
separately-use of 4 recommended
with this kit
Rnd Hd Scr 1/4-20 x 3/4"
Soc Hd Cap Scr 1/4-20 x 1-1/2"
(included with Ring Gear Assembly)
Tensioner
Rod w/Key-10" (254 mm) Long
Rod Clamp
Torches are not furnished with kit,
order separately
6
4
5
