VACUUM SUPPORT KIT

CON-1006 VACUUM SUPPORT KIT can be mounted on any CIR-O or CON-
O ring base with standard CON-1003 legs. Vacuum pump kits are available
for operation on 120 VAC [ARV-2020] or 240 VAC [ARV-2030]
Each vacuum cup holds 50 lbs (22 kg).
(Dirt and scale block vacuum lines; blow-out when clogged).
Keep flame 4" (100 mm) away from cups when burning or welding. Silicone
vacuum cups will withstand a temperature of 600°F (318° C).
ITEM PART NO.
1 ARV-1004-14
2 ARV-1005
3 ARV-1013
4 ARV-2020
ARV-2030
5 ARV-1034
6 ARV-1107
7 ARV-1109
8 ARV-1116
9 CON-1007
10 CON-1020
Vacuum Pump is not included in CON-1006 Vacuum Support Kit.
10 1
9
3
DESCRIPTION
Hose 14" (355 mm)
Hose Clamp
Male Quick Connector 1/4 NPT
Vacuum Pump Kit (I 20 VAC/60 Hz/1 Ph)
Vacuum Pump Kit (220 VAC/60 Hz/1 Ph)
Choke Nipple
3/8" Hose Barb 1/4 NPT
Protective Cap
Vacuum Cup (Silicone) 50 lbs. (22 kg)
Vacuum Leg
Double Swivel Clamp Assembly
2
6
7
8
5
4
13
