Hauler Racks ULRHDGV-1 Instructions Manual

Aluminum “universal” van / cap rack roof mount application

Advertisement

Quick Links

Before you begin:

Remove all components from the shipping carton.
The rack should be assembled on a padded surface such as carpet to prevent scratching of aluminum surfaces. Remove bands securing
components together.
Read the instructions thoroughly to familiarize yourself with the assembly sequence.
Note that you DO NOT tighten any nuts and bolts until the completed rack is installed on the vehicle unless specified. This allows for minor
adjustments to the rack during the installation process.
Gather the following tools used to assemble and install the rack.
7/16", 1/2" & 9/16" Socket or open end wrench
Phillips screw driver
5/16" dia drill bit and drill
Waterproof Silicon Sealer (optional, not included)
Marker
HAULER RACKS, INC.
st
7109 31
Avenue North
Minneapolis, MN 55427-2848
ALUMINUM "UNIVERSAL" VAN / CAP RACK
INSTRUCTIONS ROOF MOUNT APPLICATION
P/N ULRHDGV-1 / ULRHDGC-1
Page 1 of 6

Package Contents:

(8) Load Secure Posts
(2) Cross Bars
(4) Curved Arms
(4) G Mount Hinges
(4) G Mount Rubber Gaskets
(4) G Mount Flat Plates
(8) 5/16" x 1" Carriage Bolts
(8) 5/16" Nuts
(8) 5/16" Split Lock Washers
(16) 3/8-16 x 1-3/4" Bolts
(16) 3/8-16 Nuts
(16) 3/8 Split Lock Washers
(12) ¼" Nuts
(12) ¼" Split Lock Washers
(12) ¼" x 1-1/2" Phillips Screws
Toll Free: 1-800-843-5445
Phone: 763-546-5620
Fax: 763-546-0933
WWW.HAULERRACKS.COM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ULRHDGV-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hauler Racks ULRHDGV-1

  • Page 1 ALUMINUM “UNIVERSAL” VAN / CAP RACK INSTRUCTIONS ROOF MOUNT APPLICATION P/N ULRHDGV-1 / ULRHDGC-1 Package Contents: (8) Load Secure Posts (2) Cross Bars (4) Curved Arms (4) G Mount Hinges (4) G Mount Rubber Gaskets (4) G Mount Flat Plates (8) 5/16”...
  • Page 2 Secure and tighten the curved arm to the “G” mount hinge with (2) 5/16” split lock washer and (2) 5/16”-18 nut. Repeat for remaining “G” mounts hinges. 2. Assemble center load secure posts to crossbar by sliding (2) 3/8”-16 x 1-3/4” bolts into the center channel of the cross bar. HAULER RACKS, INC. Page 2 of 6 Toll Free: 1-800-843-5445...
  • Page 3 4. Slide the non-labeled load secure posts towards the center of crossbar. 5. Slide (2) 3/8”-16 x 1-3/4” bolts into the center channel of the cross bar on each end. HAULER RACKS, INC. Page 3 of 6 Toll Free: 1-800-843-5445...
  • Page 4 7. Attach the labeled end load secure posts to the cross bar end by sliding a 3/8”-16 x 1-3/4” bolts into the center channel of the cross bar on each end. HAULER RACKS, INC. Page 4 of 6 Toll Free: 1-800-843-5445...
  • Page 5 Secure the “G” mount to the crossbar with (3) ¼”-1-1/2” Phillips screws, (3) ¼” split lock washers and (3)¼” nuts. Tighten all screws. Repeat for other side. 10. Adjust center load stops as needed. Repeat for other crossbar. Tigthen all nuts and bolts after installation. HAULER RACKS, INC. Page 5 of 6 Toll Free: 1-800-843-5445...
  • Page 6 The racks have been load tested for the racks capacity to hold loads when not on a vehicle. Hauler Racks, Inc. does not warranty load capacities. As the factory has no way of knowing if the product was properly assembled, installed, used according to instructions, or if loads were secured properly.
