Parts List - 6 Oz. Kettle Assembly - Gold Medal P-60 Instruction Manual

PARTS LIST - 6 oz. KETTLE ASSEMBLY

Export
Model
Item No. Part No.
49326EX
49065EX
49327EX
1 47107
2 47106
3 47059
4 49014
5 46649
6 49013
7 49011
8 49016
9 89125
10 49030EX
11 49017
12 49312EX
13 49314
14 49446
15 47676
16 49081
17
18 49136
19 49317
20 49310
21 49368
22 49316
23 47702
24 49329
25 77079-16
26 46241
49328
27 47120
28 74150
29 87210
30 41742
33 49086
34 49087
35 49159
36 49177
37 47110
38 49350
39 49362
40 77080
Japanese
Model
Part No.
49326JX 6 Oz. Kettle Complete
49065JX 6 Oz. Lid & Agitator Assembly
49327JX 6 Oz. Kettle Bottom Only
47107 C - Ring
47106 Needle Bearing
47059 Spur Gear
49014 Agitator Shaft Assembly
46649 Set Collar
49013 Agitator Weight
49011 Stir Rod
49016 Rear Kettle Lid
89125 Screw #8-32 x ¾" (19mm) Hex HD
49030JX Crossbar Assembly
49017 Front Lid with Lifter
49312 Kettle Welded Assembly
49314 Dump Handle RH
5
49446 Bolt
47676 Primary Thermostat
49081 Heat Element 1000W
49136 Screw #6-32 x
49317 5 / -18 Serrated Lock Nut
16
49310 Element Retainer Bracket
49368 Kettle Gasket
49316 Kettle Shell
47702 Acorn Nut #8-32
49329 Kettle Plug
77079-16 Flexible Conduit
46241 90 Degree Connector
49328 Kettle Lead-In Cord Assembly
47120 Knob, Lid Lifter
74150 #8 Lock Washer
87210 Screw #8-32 x
41742 Set Screw #8-32 x
49086 Red Kettle Wire Assembly
49087 White Kettle Wire Assembly
49159 Green Kettle Wire Assembly
49177 Screw #8-32 x ¾" (19mm) Hex HD
47110 Knob, Dump Handle
49350 Caution Label
49362 Dump Handle Spacer
77080 Bushing, Conduit
9
Description
5
/ -18 x / " (15,9mm) Square HD
16 8
3 / " (4,8mm) Pan HD MS
16
3 / " (9,5mm)
8
3 / " (9,5mm)
8
A E M #1866, #2085, #2086
LL XPORT ODELS
60 Special P-60
and
#2656
AND
