1-4
Indroduction
Power Section
The following are connected to the power section:
• mains voltage
• motor
• 24 V power supply (optional)
• module bus (for cross communication in the case of DC bus
connection with other devices)
• motor holding brake (optional)
• motor temperature sensor (optional)
• braking resistor (optional)
Control Section
The control section is a separate component that is plugged into the
power section. The drive controller is supplied ex works complete with
control section.
The control section may only be replaced by qualified personnel.
The contacts X31/1 and X31/2 are connected to the control section as Bb
contacts.
Note: The control
documentation (see page 1-2).
Rexroth IndraDrive C HCS03.1
sections are described
DOK-INDRV*-HCS03.1****-PR02-EN-P
in a separate
