- Page 1 CS 106 Proportional Paddle Joystick Controller Setup Manual...
-
Page 2: Table Of Contents
MOUNTING OPTIONS ....................6 Bosch Rexroth Canada Corp. reserves the right to revise this information at any time and for any reason and reserves the right to make changes at any time, without notice or obligation, to any of the information contained in this piece of literature. -
Page 3: Layout
1 LAYOUT The CS 106 is a customized proportional controller utilizing single axis paddles or 1 to 3 axis joysticks. All outputs can have minimum and maximum trim values to provide precise hydraulic control. Configurable Park set points allow multiple outputs to be activated at the same time to provide an emergency raise or convenient stow option. -
Page 4: Program Mode
3 PROGRAM MODE Program mode is used to set min and max trim values for Paddle / Joystick functions and to set Park / Emergency function. Paddles / Joystick functions will have full range of hydraulic output and Deadman button is not required while in program mode. To enter Program mode: 1. -
Page 5: Fault Messages
CLEARING PARK / EMERGENCY VALUES In program mode with all Paddle / Joystick functions at neutral positions, hold park button until three audible beeps are heard (to warn that park values will be cleared), followed by one long beep to indicate all park values have been cleared. 6 DIAGNOSTIC FAULT MESSAGES By default, diagnostic messages are disabled (Diagnostic messages were always enabled on firmware version 13 and below). -
Page 6: Cable Connections
CABLE CONNECTIONS 10 Amp AGC fuse Refer to the Order Specific Documentation for custom functionality of each console. -
Page 7: Mounting Options
MOUNTING OPTIONS The three available mounting options are: 1 - RAM ball 2 - Pedestal tube 3 – Armrest 4x 10-32 bolts from the bottom fasten the armrest...
