- Page 1 INSTALLATION AND MAINTENANCE GUIDE BC633F E L E C T R O N I C F O A M S O A P D I S P E N S E R Saving soap, saving power, promoting hygiene Important: Read carefully before installing product...
-
Page 2: Table Of Contents
INDEX Technical Data Pre-Installation Info Pack Contents Installation Filling The Soap Tank Settings Adjustment Spare Parts List Maintenance Warranty 15-17 Troubleshooting Dolphin BC 633F... -
Page 3: Technical Data
Capacity 1 Litre 33.8 oz. Power Supply 12V transformer Soap viscosity up to 100 cPs Standard discharge Varies according to viscosity and soap consistency Sensor range 30-100 mm ± 10 mm /1.18-3.94” (customisable by optional remote control) Dolphin BC 633F... -
Page 4: Pre-Installation Info
IMPORTANT: Keep in mind that when using the tap installed next to the soap dispenser, the user hands should not interfere with the soap dispenser sensor detection area. Correct Installation Incorrect installation DO NOT AIM SOAP SENSOR AT WATER STREAM Dolphin BC 633F... - Page 5 Dolphin foam soap dispensers are suitable for use with any generic liquid soap of the correct viscosity and pH. The pH level of all soap used in Dolphin foam soap dispensers should be between 6.5 to 8.5. Lower levels will cause corrosion to the metal dispenser and even the rubber and plastic components.
-
Page 6: Pack Contents
Familiarise yourself with the part names and confirm that the parts are included. 1 x foam dispenser body 12v transformer 1 x foam compressor with pipe 1 x pump assembly with bottle support and soap tank 2 x screws and 2 x anchors Dolphin BC 633F... - Page 7 Step 2 – installing the soap dispenser Insert the soap dispenser body and the anti rotation pin along with the rosette into the holes drilled. Under the deck, secure the gasket, disk and nut over the soap dispenser body nipple. Dolphin BC 633F...
- Page 8 IMPORTANT: Make sure to cut the soap tube to the minimum required length Dolphin BC 633F...
- Page 9 3. Plug the transformer into the electricity socket and connect the transformer FROM THE TRANSFORMER TO THE SOAP DISPENSER connector 4. Wait about 10 seconds before placing your hands in the sensor range to avoid ABOUT adjustment mode. SECONDS Dolphin BC 633F...
-
Page 10: Filling The Soap Tank
FILL function on the remote control (if available). see page 11. Note : When the soap in the soap tank reaches the bottom line, the tank needs to be refilled. To refill the soap tank please refer to steps 1-5. Dolphin BC 633F... -
Page 11: Settings Adjustment
Once soap begins dispensing from the spout, priming is complete. press the FILL button again to stop the priming before the minute is over. Indication: continuous solid blue light in the sensor eye. Dolphin BC 633F... -
Page 12: Spare Parts List
BC07100035 6-pack 1L Bottle Support KIt BC07100037 12V Transformer (EU) BC06522081 12V Transformer (UK) BC06522086 12V Transformer (US) BC06522080 12V Transformer (AU) BC06522085 Remote Control for Foam Dispenser (Optional) BC07100009 Soap & Water Remote Control (Optional) BC01700014 Dolphin BC 633F... -
Page 13: Maintenance
Clean out the tank prior to refill by flushing warm water through the hoses and pump until clean water is released from the spout. TIP: Keeping a spare tank will enable this process to be completed in a speedy and hygienic manner with minimal downtime. Dolphin BC 633F... -
Page 14: Warranty
If a defect is found in normal use, Dolphin Solutions Ltd. will, at its discretion, repair, provide a replacement part or product, or make appropriate adjustments. Damage caused by accident, misuse, or abuse is not covered by this warranty. - Page 15 NOTE: Using the soap dispenser with high High viscosity soap viscosity soap may cause permanent (>100 cPs) damage to the pump and shorten the lifecycle. ap V Bent pipes Unbend or straighten pipes. Dolphin BC 633F...
- Page 16 Replace with soap of correct viscosity. NOTE: Using the soap dispenser with high viscosity ap d pe se soap may cause permanent damage to the pump and shorten the lifecycle. Dolphin BC 633F...
- Page 17 "- Air" Key. Foam is too Use remote to increase the t t i liqueied amount f air in the f foam by pressing the " + Air" key. Dolphin BC 633F...
