3 0 0 M
A R L I N
A i r C o n d i t i o n i n g L a y o u t & A s s e m b l y
A/C Control Panel
4" Closable Round Vent
AC Control
AC Drain
Panel Harness
7,000 BTU Air
Conditioning Unit
AC/DC Panel
Return Vent
4" Insulated Duct
4" Closable Round Vent
AC Wiring
AC Intake Strainer
AC Intake Seacock
AC Water Pump
8–24
