Dear Grady-White Owner:
Welcome aboard!
Buying and owning a boat is a very special experience. Of all the many products you'll ever
own we want your Grady-White experience to be the absolute best. That means providing the
descriptions, explanations and technical support that you need to enjoy your Grady-White with
confidence and security.
Your Grady-White exceeds all US Coast Guard safety standards and is built to standards
certified by the National Marine Manufacturers Association (NMMA). Best of all, your boat is
built to Grady-White standards, standards that have served our owners through some truly
extraordinary conditions since our first models built in 1958.
The seaworthiness and safety of your Grady-White is highly dependent on the operation,
maintenance and care of your boat, so please read this manual thoroughly and keep it around for
reference. If you need further explanation or "hands-on" help, don't hesitate to ask the people at
your Grady-White dealership; they have experience with the systems and operations of your boat.
If for any reason you need additional help, please feel free to call us at the factory. We sincerely
want to provide you with the help and information that will make your Grady-White experience
delightful.
Thanks for choosing a Grady-White. All of us at the factory and at your dealership are
dedicated to earning your confidence in Grady-White Boats. Again, welcome aboard.
Sincerely yours,
Kris Carroll
President
Grady-White Boats, Inc.
5121 Martin Luther King Jr. Hwy, Greenville, NC 27834 • P.O. Box 1527 • Greenville, NC 27835-1527
Tel: 252-752-2111 • Fax: 252-752-4217 • http://www.gradywhite.com
Grady-White Boats, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Express 305 and is the answer not in the manual?

Questions and answers

Jeffrey Parrish
July 10, 2025

what raw water pump is in the 2007 Grady White 305 Express

0
