Welcome Aboard!

D e a r G r a d y - W h i t e O w n e r :
Welcome aboard!
Buying and owning a boat is a very special experience. Of all the many products you'll ever
own we want your Grady-White experience to be the absolute best. That means providing the
descriptions, explanations and technical support that you need to enjoy your Grady-White with
confidence and security.
Your Grady-White exceeds all US Coast Guard safety standards and is built to standards
certified by the National Marine Manufacturers Association (NMMA). Best of all, your boat is
built to Grady-White standards, standards that have served our owners through some truly
extraordinary conditions since our first models built in 1958.
The seaworthiness and safety of your Grady-White is highly dependent on the operation,
maintenance and care of your boat, so please read this manual thoroughly and keep it around for
reference. If you need further explanation or "hands-on" help, don't hesitate to ask the people at
your Grady-White dealership; they have experience with the systems and operations of your boat.
If for any reason you need additional help, please feel free to call us at the factory. We sincerely
want to provide you with the help and information that will make your Grady-White experience
delightful.
Thanks for choosing a Grady-White. All of us at the factory and at your dealership are
dedicated to earning your confidence in Grady-White Boats. Again, welcome aboard.
Sincerely yours,
Kris Carroll
President
Grady-White Boats, Inc.
5121 Martin Luther King Jr. Hwy, Greenville, NC 27834 • P.O. Box 1527 • Greenville, NC 27835-1527
Tel: 252-752-2111 • Fax: 252-752-4217 • http://www.gradywhite.com
Grady-White Boats, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EXPRESS 360 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Grady-White Boats EXPRESS 360

Summary of Contents for Grady-White Boats EXPRESS 360

  • Page 1: Welcome Aboard

    Grady-White experience delightful. Thanks for choosing a Grady-White. All of us at the factory and at your dealership are dedicated to earning your confidence in Grady-White Boats. Again, welcome aboard. Sincerely yours, Kris Carroll President Grady-White Boats, Inc.

  • Page 3: Table Of Contents

    A B L E O F O N T E N T S A B L E O F O N T E N T S E L C O M E B O A R D A B L E O F O N T E N T S 1 : C H A P T E R...
  • Page 4 A B L E O F O N T E N T S S w i t c h P a n e l ....... 4 – 7 5 : P H A P T E R E R F O R M A N C E...
  • Page 5 A B L E O F O N T E N T S Batteries ..........7–3 Engines .
  • Page 6 A B L E O F O N T E N T S Helm Air Conditioner........... . . 8–18 Microwave .
  • Page 7 A B L E O F O N T E N T S 12 Volt DC Hardtop Elementary Diagram ....8–54 12 Volt DC Trim Tab Diagram ......8–55 12 Volt DC Cockpit Switch Panel Diagram .
  • Page 8 A B L E O F O N T E N T S...

  • Page 9: Information

    • A warranty card to be completed and signed by the dealer and the customer. This warranty card is to be sent to Grady-White Boats to validate the warranty. • An explanation of safety issues regarding the use of containment systems and components.

  • Page 10: Consumer Responsibilities

    • Return the boat to the selling dealer for an engine inspection. Refer to the engine’s owner’s manual for the proper maintenance schedule. Grady-White Boats has a permanent record of your boat which is retained under its “Hull Identification Number” (HIN). Data regarding equipment and accessories, as well as dealer/ shipping information is documented.

  • Page 11: Hazard Warning Labels

    E L C O M E AZARD ARNING ABELS The hazard warning labels shown below are applied throughout this manual to alert the customer of potentially dangerous situations that can lead to death, personal injury, and/or product damage. We urge you to observe these warnings and comply with all safety recommendations. D A N G E R This symbol alerts you to imminently hazardous situations which WILL cause severe personal injury or death if the warning is ignored.
  • Page 12 E L C O M E 1–4...

  • Page 13: A F E T Y

    USCG approved visual distress signals are required on U. S. waters. See page 33 of the pamphlet Sportfish, Cruisers, Yachts Owner’s Manual enclosed with this manual for more information. • Lighting Grady-White boats are equipped with navigational lights that meet requirements for recreational vessels for inland and international waters. DDITIONAL ECOMMENDED...

  • Page 14: Emergency Stop Switch

    A F E T Y MERGENCY WITCH All Grady-Whites are equipped with an emergency stop switch. This is a safety feature that if used properly will shut the engine(s) down if the operator leaves or falls from the helm position. The ignition shutdown system includes a shut-off switch, switch clip, lanyard and lanyard clip.

  • Page 15: Boating Safety Tips

    A F E T Y OATING AFETY Safety is an important aspect of boating. Your safety as well as the safety of your passengers and vessel is your responsibility. The following precautions and the ones mentioned in section 1 of Sportfish, Cruisers, Yachts Owner’s Manual will add to you and your passengers’ boating safety and pleasure.

  • Page 16: Certification

    A F E T Y ERTIFICATION This label means your Grady-White is certified by the National Marine Manufacturers Association (NMMA). With this tag, you are assured the fuel system, electrical system, navigation lighting, ventilation, steering and other design elements are not only in compliance with the US Coast Guard regulations, but also meet the more stringent standards of the NMMA.

  • Page 17: Loading Capacity

    ON THE DATE OF CERTIFICATION IS VERIFIED. MANUFACTURER RESPONSIBLE FOR QUALITY CONTROL NATIONAL MARINE MANUFACTURERS ASSOCIATION THIS BOAT COMPLIES WITH U.S. COAST GUARD SAFETY STANDARDS IN EFFECT ON THE DATE OF CERTIFICATION MEETS U.S. EPA EVAP STANDARDS USING CERTIFIED COMPONENTS GRADY-WHITE BOATS, INC., GREENVILLE, NC 2–5...

  • Page 18: Carbon Monoxide

    A F E T Y ARBON ONOXIDE W A R N I N G (CO) is produced by all combustion engine(s) and generator sets. Avoid brain damage or death from carbon monoxide. Keep cockpit and cabin areas well ventilated. Avoid blockage of exhaust outlets. Signs of exposure include headache, nausea, dizziness and drowsiness.

  • Page 19: Suggested Boating Classes And Reading Material

    A F E T Y UGGESTED OATING LASSES EADING ATERIAL Like a car, boats must be operated according to safety rules and traffic regulations. Although we include some basic boating tips in this manual, a thorough review of the safety rules and regulations for boating is beyond the scope of this text.
  • Page 20 A F E T Y 2–8...

  • Page 21: E N E R A L

    E N E R A L N F O R M A T I O N C h a p t e r 3 : G e n e r a l I n f o r m a t i o n UELING W A R N I N G Safety during fueling requires CAUTION and COMMON SENSE.

  • Page 22: Fuel System

    E N E R A L N F O R M A T I O N See warnings and check list in Section 6, page 37 of the Sportfish, Cruisers, and Yachts Owner’s Manual. Reference “Fuel Tank Compartment” on page 6–7 for more information on cleaning the fuel storage area.

  • Page 23: Fuel Select Valve

    E N E R A L N F O R M A T I O N ELECT ALVE If your boat is equipped with dual fuel tanks, you will have a manual fuel select valve installed. This valve allows you to choose from which tank fuel will be consumed. Remember, as the fuel is consumed and the fuel load redistributes, the performance will be influenced.

  • Page 24: Discharge Of Oil Or Hazardous Substances

    E N E R A L N F O R M A T I O N Discharge of Oil or Hazardous Substances The Federal Water Pollution Control Act prohibits the discharge of oil or hazardous substances, which may be harmful, into or upon U.S. navigable waters. Vessels 26 feet (7.9m) in length or over must display a placard at least 5”...

  • Page 25: Environmental Protection Agency

    ROTECTION GENCY All Grady-White boats meet the Environmental Protection Agency standards in effect at the time of manufacture and boats 26’ (7.9m) and below have an EPA label located in the same area as the NMMA label. Boats 27’ (8.2m) and above have the EPA label incorporated within the NMMA yacht certification label.

  • Page 26: Towing

    E N E R A L N F O R M A T I O N W A R N I N G Never anchor off the stern of the boat especially in strong winds or currents. The weight of the stern and flat surface to the seas can easily cause water to enter over the transom and swamp the boat.

  • Page 27: General Information On Boat Handling

    E N E R A L N F O R M A T I O N Be mindful of water level fluctuations when boating in water with tidal changes. If you are grounded on an incoming tide, you can wait until the tide is high enough to refloat your boat. However, on an outgoing tide, quick action should be taken to refloat your boat.
  • Page 28 E N E R A L N F O R M A T I O N OMMONLY AUTICAL ERMS Access Plate Port Side Stern Beam Gunwale Starboard Side Bow Eye Chine Keel Abeam - a line perpendicular to a Deck - upper structure which Lee - the side that is sheltered from boat’s keel covers the hull...

  • Page 29: N S T R U M E N T A T I O N A N D

    N S T R U M E N T A T I O N A N D W I T C H E S C h a p t e r 5 : I n s t r u m e n t a t i o n a n d S w i t c h e s AMAHA NSTRUMENTATION ANEL...

  • Page 30: Digital Tachometer

    N S T R U M E N T A T I O N A N D W I T C H E S • Speedometer This feature indicates boat speed in miles per hour, knots per hour, or nautical miles per hour. On boats with V8 engines, this gauge must be interfaced with a GPS.
  • Page 31 N S T R U M E N T A T I O N A N D W I T C H E S Yamaha Command Link Plus Display This Yamaha display provides engine and boat information listed below. The display of these functions and other graphics may be customized.
  • Page 32 N S T R U M E N T A T I O N A N D W I T C H E S • Revolutions Per Minute (RPM) This feature indicates the RPM using 100 RPM intervals. Consult your engine owner's manual for the recommended operating RPM range.

  • Page 33: Triple Instrumentation

    N S T R U M E N T A T I O N A N D W I T C H E S RIPLE NSTRUMENTATION IGITAL ANAGEMENT • Fuel Management Meter This feature indicates the gas tanks fuel efficiency (MPG), fuel consumption (gallons), and fuel flow (GPH) for each engine or all engines together.

  • Page 34: Digital Tachometer

    N S T R U M E N T A T I O N A N D W I T C H E S • Trip Distance Meter This feature indicates the distance traveled in miles or nautical miles since the meter was last set.

  • Page 35: Switch Panel

    N S T R U M E N T A T I O N A N D W I T C H E S WITCH ANEL At the helm station you will find an accessory switch panel. Not all boats are equipped with the same accessories.
  • Page 36 N S T R U M E N T A T I O N A N D W I T C H E S 5–8...

  • Page 37: E R F O R M A N C E

    E R F O R M A N C E C h a p t e r 4 : P e r f o r m a n c e ERFORMANCE ACTORS Maximum performance is dependent on many factors and cannot be guaranteed. These factors will vary with changing conditions.

  • Page 38: Propeller

    E R F O R M A N C E Propeller The condition of your prop has a major influence on the performance of your boat. Your engine(s) should be equipped with the best size prop for normal conditions. Unusual uses or weight conditions may require special props.

  • Page 39: Propulsion System - Outboard

    E R F O R M A N C E – O ROPULSION YSTEM UTBOARD The engine manufacturer supplies all vital information concerning your engine(s) in the Operation and Maintenance Manual(s). Details of important engine functions such as the lubrication system, cooling system, and alarm/monitoring system are outlined in these manuals. Your familiarization with this engine reference material will result in the proper usage and service essential for safe and enduring engine performance.

  • Page 40: Steering

    • Mechanical Steering Grady-White boats that use mechanical steering are equipped with No Feedback Mechanical Steering. No feedback steering provides easier steering and increased control by offsetting the engine(s) torque.

  • Page 41: Throttle/Shiftcontrols

    E R F O R M A N C E HROTTLE HIFT ONTROLS The throttle/shift controls located at the helm station control the flow of fuel to the engine. They also act as gear shift levers to control the forward and reverse thrust of the propellers. The middle position of the throttle control is the neutral position.
  • Page 42 E R F O R M A N C E Reverse the shift mechanism to stop a boat that is moving forward. This change in direction will provide a “braking action” and slow the boat.Boats with three outboard engines are equipped C A U T I O N The braking action causes a wake which may wash over the transom and flood the boat if the vessel is moving too fast.

  • Page 43: A I N T E N A N C E A N D

    A I N T E N A N C E A N D E R V I C E C h a p t e r 6 : M a i n t e n a n c e a n d S e r v i c e ENERAL The amount of maintenance required to keep your boat operating properly and to maintain the appearance is dependent on how the boat is used, amount of usage, salt or fresh water, geographic...

  • Page 44: Finish/Waxing

    A I N T E N A N C E A N D E R V I C E Finish/Waxing Gel-coat will age or dull naturally due to constant exposure to the natural environment and pollutants. Discolorations are shallow in depth. Factors that will affect the rate of discoloration are: the sun, pollution, old wax accumulation, and the salt content of water.

  • Page 45: Repairing

    A I N T E N A N C E A N D E R V I C E Repairing Though gel-coat is a very durable material, it is susceptible to scratches, blistering, and web- like cracking (crazing) over time. It is elastic enough to withstand strong blows while flexing with the hull's movement.

  • Page 46: Canvas

    A I N T E N A N C E A N D E R V I C E Brackets are equipped with a drain plug in the bottom of the bracket near the transom. This plug should only be used if water is found inside the bracket. When replacing drain plug, coat threads with a Teflon thread sealant and do not over tighten.

  • Page 47: Storage

    CUPPERS Grady-White boats have self-bailing cockpits meaning water on the cockpit floor drains by gravity through large aft scuppers and not into the bilge. The aft drains (scuppers) have an external scupper flap assembly that restricts the flow of water back into the boat.

  • Page 48: Caulking/Gasket

    A I N T E N A N C E A N D E R V I C E AULKING ASKET Deck fittings, bow rails, windows, hatches, etc. have been caulked or gasketed with the highest quality material to ensure a waterproof joint with the boat. However, the working action of normal use will tend to flex the joint and eventually break down the seal between them.

  • Page 49: Fuel System Maintenance

    A I N T E N A N C E A N D E R V I C E ETAL ROTECTORS Boeshield T-9 Aluma Guard Premier Polish PMS Products Inc. Rupp Marine, Inc. Aquatech by Nautical Choice 76 Veterans Dr. 4761 Anchor Ave.

  • Page 50: Shower Sump

    A I N T E N A N C E A N D E R V I C E HOWER A shower in the head compartment drains into a contained “sump” which is used to prevent hair, soap, scum and bacteria from accumulating in the bilge and creating odors. This sump should be cleaned regularly.

  • Page 51: Inverter Batteries

    A I N T E N A N C E A N D E R V I C E W A R N I N G Do not allow any electrically conductive material to make contact with both the positive and negative terminals at the same time (i.e.

  • Page 52: Light Bulb Replacement Guide

    A I N T E N A N C E A N D E R V I C E IGHT EPLACEMENT UIDE The following chart provides identification of replacement light bulbs for your Grady-White. All of the lights shown may not be used on every model boat. If you have difficulty finding replacement bulbs under the part numbers listed, contact your Grady-White dealer for further assistance.

  • Page 53: Led Light Guide

    A I N T E N A N C E A N D E R V I C E LED L IGHT UIDE LED (light emitting diode) fixtures do not have bulbs and are not serviceable. LED’s have extremely long life and should not need replacement during the life of the boat. In the event of damage or malfunction, the entire light assembly should be replaced.

  • Page 54: Accessory Wiring Color - Fuse/Breaker

    A I N T E N A N C E A N D E R V I C E CCESSORY IRING OLOR REAKER 180-283, 306 & 307 DC Wiring Accessory Wire Amperage Location Lights Aft Pole Light 14 ga. Gray/White 10.0 w/ Bow Light Accessory Panel Bow Light 14 ga.

  • Page 55: Anchor Windlass

    A I N T E N A N C E A N D E R V I C E 180-283, 306 & 307 DC Wiring Accessory Wire Amperage Location Horn (180-209, 255, 257, 275, 283,) 12 ga. Orange/White Accessory Panel Horn (225, 226, 228, 232, 258, 306, 307) 12 ga.
  • Page 56 A I N T E N A N C E A N D E R V I C E 290-305, 330, 336, & 366 DC Wiring CO Detector 16 ga. Red/Black Positive bus (in line) / 336 console fuse block Constant 12V (Memory, High Bilge Alarm) 16 ga.
  • Page 57 A I N T E N A N C E A N D E R V I C E 360 DC Wiring Accessory Wire Amperage Location Lights Bow Light 14 ga. Gray 10.0 Helm Accessory Panel Cabin Lights 16 ga. Blue/Green 20.0 AC/DC Panel Cockpit Lights...
  • Page 58 A I N T E N A N C E A N D E R V I C E 6–16...

  • Page 59: I N T E R I Z A T I O N A N D

    Manual for a checklist on winterizing and storage. TORAGE Grady-White boats are equipped with stern eyes and a bow eye. These eyes are for anchoring and trailering purposes, and should be inspected regularly to insure structural integrity. W A R N I N G The boat should not be lifted for storage using the bow and stern eyes.

  • Page 60: Cleaning And Lubricating The Boat

    I N T E R I Z A T I O N A N D T O R A G E For outdoor storage, a canvas cover should be used to prevent “sweating”. One method is to build a frame over the boat to support the canvas. It should be a few inches wider than the boat so the canvas will clear the rails and allow passage of air.

  • Page 61: Head System

    I N T E R I Z A T I O N A N D T O R A G E YSTEM Empty toilet and holding tank making sure all water is cleared. Reference Owner’s Packet for manufacturer’s information on winterization. Water should be removed from deck pump-out hoses.

  • Page 62: Fuel System

    I N T E R I Z A T I O N A N D T O R A G E YSTEM The fuel systems should be winterized by following the fuel system maintenance and fuel tank compartment instructions in the maintenance and service section. Tanks should be kept filled when the boat is not in use to reduce the accumulation of moisture and condensation.
  • Page 63 I N T E R I Z A T I O N A N D T O R A G E Fuel System - Section A Pink (Main) or Pink/White (Aux) Wire to Fuel Gauge, Hull Harness Green Ground Wire to Battery (-) Green Jumper (Aluminum Tanks Only)

  • Page 64: Storage Checklist

    I N T E R I Z A T I O N A N D T O R A G E TORAGE HECKLIST In addition to winterization guidelines the following checklist can be used as a guide for storing your boat. Additional details should be added as needed for your personal application. •...

  • Page 65: After Launching

    I N T E R I Z A T I O N A N D T O R A G E FTER AUNCHING • With the boat in the water, check all sources of possible leaks stem to stern. • Thoroughly check the fuel system including lines, fittings, connections, valves, and filters for leaks.
  • Page 66 I N T E R I Z A T I O N A N D T O R A G E 7–8...

  • Page 67: S P E C I F I C A T I O N S

    3 6 0 E X P R E S S C h a p t e r 8 : 3 6 0 E x p r e s s S p e c i f i c a t i o n s Beam-Amidship....................

  • Page 68: O P E R A T I O N O F S T A N D A R D F E A T U R E S

    3 6 0 E X P R E S S O p e r a t i o n O f S t a n d a r d F e a t u r e s WITCH ANELS At the helm you will find an accessory switch panel. An additional switch panel is located above the port bait station in the cockpit.
  • Page 69 3 6 0 E X P R E S S • Underwater Lighting (optional) This switch activates the underwater lights. A circuit breaker located above this switch provides over-current protection for this circuit. • Washdown This switch activates the washdown system. A circuit breaker located above this switch provides over-current protection for this circuit.

  • Page 70: Other Switches

    3 6 0 E X P R E S S • Windshield Vent This momentary switch activates the actuator which opens and closes the center vent in the windshield. A circuit breaker located above this switch provides over-current protection for this circuit.

  • Page 71: Auxiliary Fuse Panel

    ELECT WITCH The Express 360 is equipped with five batteries. One of the batteries is designated for the bow thruster and the steering power assist pump. It is located behind the fold-out helm table. The other four batteries are located in the aft rigging area under the drop-in box, and provide power for the remaining accessories as well as starting the outboard engines and generator.

  • Page 72: Bilge Pump With Float Switch

    3 6 0 E X P R E S S starboard switch and position “2” on the port switch so that both battery banks will charge simultaneously with the engines running. If the boat has triple engines, the center switch may be set in position “1”...

  • Page 73: High Bilge Water Alarm

    3 6 0 E X P R E S S ILGE ATER LARM Your boat is equipped with a high bilge water alarm. Although some residual accumulation of water in the bilge is normal, this alarm will alert you if water reaches a high level that could impair operation of the boat or be damaging to equipment.

  • Page 74: Seacocks

    AC/DC P ANEL The Express 360 AC/DC panel is located on the aft wall of the cabin. AC and DC powered switches are noted below. See “AC/DC Panel Wiring – One-Line Diagram” on page 8–48 for a wiring diagram.

  • Page 75: Ac Power Distribution - Shore 1, Shore 2, And Generator

    3 6 0 E X P R E S S 120 VOLTS A.C. 60HZ POWER AVAILABLE REVERSED POLARITY SHORE 1 GENERATOR 8238 AC AMMETER BLUE SEA SYSTEMS 8237 AC VOLTMETER BLUE SEA SYSTEMS 8238 AC AMMETER BLUE SEA SYSTEMS LOAD GROUP LOAD GROUP 1 LOAD GROUP 2 BATTERY...

  • Page 76: Using One Shore Connection Only

    3 6 0 E X P R E S S Using One Shore Connection Only To use one shore connection only, ensure the shore 1 circuit is connected to shore power. See “Connecting The Dockside Power” on page 8–13 for instructions on how to connect to shore power.
  • Page 77 3 6 0 E X P R E S S • Air/Cooler Pump Switch This load group 2 switch provides power to the water pump relay which in turn powers the water pump for the air conditioner and cockpit coolers. This switch must be engaged to operate the air conditioner, but is not required for the cockpit coolers —...

  • Page 78: Dc Powered Accessory Switches

    This switch also powers the freshwater level indicator in the head compartment. See “Pressurized Freshwater” on page 8–23 for details about the freshwater system on your Express 360. • Head Switch This switch provides power to the vacuum pump integrated within the head system. Without engaging this switch, the head will not operate.

  • Page 79: Dockside Power

    3 6 0 E X P R E S S • Shower Sump Switch This switch provides power to the pump located in the shower sump under the aft berth floor. The pump will not run until activated by the float switch. See “Shower Sump Pump” on page 8–23 for more details.

  • Page 80: Disconnecting The Dockside Power

    3 6 0 E X P R E S S 7. Turn the shore circuit breaker on the AC panel to the “on” position. W A R N I N G If the reverse polarity indicator on the AC panel is activated, immediately disconnect the dockside power cable, and have a qualified electrician correct the fault.

  • Page 81: Starting The Generator

    3 6 0 E X P R E S S • Battery Charger 6.3 Amps (3.2) 50H Maximum Amps • Bow Thruster Charger 2.0 Amps (1.0) 50H Maximum Amps • Cockpit Coolers 6.6 Amps (3.3) 50H Running Amps • Electric Stove 10 Amps (5.0) 50H Maximum Amps...

  • Page 82: Blower

    3 6 0 E X P R E S S Blower A blower is included to provide ventilation to the generator engine compartment and should run at least 4 minutes before starting the generator. Using the blower does not take the place of checking the engine compartment by sight and smell for gasoline vapors.

  • Page 83: Air/Cooler Pump

    3 6 0 E X P R E S S C A U T I O N To avoid restriction due to debris in the raw water intake strainer, turn off the air conditioner and close the intake seacock while docking or operating in shallow water. Air/Cooler Pump The air/cooler pump supplies raw water to the air conditioner, refrigeration unit for the cooler boxes, and the helm air conditioner.

  • Page 84: Freezer/Refrigerated Box System

    3 6 0 E X P R E S S Freezer/Refrigerated Box System The aft fishbox and port cockpit insulated coolers are also refrigerated. The cockpit coolers switch on the AC panel must be on to cool these boxes. It is not required to have the air/cooler pump switch on and the air condition seacock open to cool these boxes, but it is recommended.

  • Page 85: Microwave

    3 6 0 E X P R E S S C A U T I O N To avoid restriction due to debris in the raw water intake strainer, turn off the helm air conditioner and close the intake seacock while docking or operating in shallow water. Load group 2 on your distribution panel contains the air cooler pump, air conditioner, helm air conditioner, and the refrigerated boxes.

  • Page 86: Refrigerator

    Stove Located at the galley, the Express 360 stove is a glass dual element cooktop which operates by AC current only. Therefore the generator must be operating or the dockside power must be connected with load group 1 energized prior to use.

  • Page 87: Dc Powered Accessories

    3 6 0 E X P R E S S DC P OWERED CCESSORIES Bow Thruster The bow thruster aids in maneuvering your boat. The outboard engines can control the direction of the stern while the bow thruster moves the bow. Use the joystick control located at the helm to control the thruster.

  • Page 88: Freshwater Washdown

    3 6 0 E X P R E S S Freshwater Washdown To operate the freshwater washdown, turn on the water pressure switch on the AC/DC switch panel. This system will now be pressurized at the “freshwater” washdown outlet. A hose with a spray nozzle attached may be used intermittently without turning the switch off in the same fashion as a home garden hose with a nozzle.

  • Page 89: Pressurized Freshwater

    Pressurized Freshwater The Express 360 comes with a 54 gallon (204 L) pressurized freshwater system. The pump is activated at the AC/DC panel and supplies water from the water tank to the freshwater components on board. The pump and accumulator tank can be accessed through the panel in the port wall of the aft berth compartment.

  • Page 90: Sirius Satellite Radio

    3 6 0 E X P R E S S Sirius Satellite Radio The Sirius satellite radio includes the Sirius satellite tuner and antenna which provides access to many channels of digital entertainment. The antenna is installed on the forward bow area away from any structure that may cause signal interference.

  • Page 91: Trim Tabs

    3 6 0 E X P R E S S Trim Tabs Trim tabs are electrically and hydraulically operated. The trim tab system includes a hydraulic pump, a switch with an integrated indicator, and an auto-retract feature. The switch controls the pump which lowers and raises the trim tabs.

  • Page 92: Tv/Dvd

    X P R E S S Trim Tab Pump Location The Express 360 trim tab pump is located on the port hull side, and is accessed through the wall panel in the aft berth compartment. The hydraulic fluid should be checked on a seasonal basis.
  • Page 93 3 6 0 E X P R E S S 3. To flush, depress the flush lever sharply until contents clear the bowl. A sharp popping noise is normal when the vacuum seal is broken and flushing begins. Be sure to hold the lever down for 3 seconds.

  • Page 94: O P E R A T I O N O F O P T I O N A L F E A T U R E

    3 6 0 E X P R E S S O p e r a t i o n O f O p t i o n a l F e a t u r e s – UTRIGGER 15’ Top Mount Radial;...

  • Page 95: Fuel System

    3 6 0 E X P R E S S I n f o r m a t i o n a l D r a w i n g s F u e l S y s t e m Fuel Fill 180 Gallon &...

  • Page 96: Air Conditioning Layout

    3 6 0 E X P R E S S A i r C o n d i t i o n i n g L a y o u t 5" Insulated Duct 5" Insulated Duct 4" x 8" Teak Grill Air Condition Thru Hull 4"...

  • Page 97: Helm Air Conditioning Layout

    3 6 0 E X P R E S S H e l m A i r C o n d i t i o n i n g L a y o u t AC/DC Panel Air Control Panel Pump Relay (accessed by panel in stbd aft berth wall)

  • Page 98: Cockpit Coolers Layout

    3 6 0 E X P R E S S C o c k p i t C o o l e r s L a y o u t Refrigeration Relay (RR) (access relays, solenoid valves, and condensing unit by panel in port aft berth wall panel) Coolers Solenoid Pump Relay (PR)

  • Page 99: Livewell/Washdown System Layout

    3 6 0 E X P R E S S L i v e w e l l / Wa s h d o w n S y s t e m L a y o u t Washdown Outlet Washdown Seacock (accessed by removing cover 1100 gph(4164 lph) Livewell...

  • Page 100: Vacuflush® Head Layout

    3 6 0 E X P R E S S Va c u F l u s h ® H e a d L a y o u t Vacuflush Tank Manager Panel & Water Level Gauge Vacuflush Head Discharge Seacock (accessed by removing the cover board Vacuum Tank...

  • Page 101: Pressurized Freshwater System Layout

    3 6 0 E X P R E S S P r e s s u r i z e d F r e s h w a t e r S y s t e m L a y o u t Refrigerator Freezer w/ Ice Maker Refrigerator Shut-off Valve...

  • Page 102: Access Plate And Hull Rigging Tube Locations

    3 6 0 E X P R E S S A c c e s s P l a t e A n d H u l l R i g g i n g T u b e L o c a t i o n s Description 3"...

  • Page 103: Liner Rigging Tubes

    3 6 0 E X P R E S S L i n e r R i g g i n g T u b e s Description 3" x 80" (2.0 m) 3" x 36" (91 cm) 3" x 30" (76 cm) 8–37...

  • Page 104: Safety Labels And Location

    3 6 0 E X P R E S S S a f e t y L a b e l s A n d L o c a t i o n CAUTION TO AVOID PERSONAL INJURY, KEEP HANDS FREE OF WINDLASS AND ROPE WHEN OPERATEING On AC/DC Panel WARNING...

  • Page 105: Thru Hull Detail

    3 6 0 E X P R E S S T h r u H u l l D e t a i l Description Description Scupper Drains Air Conditioner Discharge Aft Fishbox Drain Galley Sink Drain Gen Exhaust Fwd Bilge Stbd Sink Drain Condensor Drain Livewell Drain/Overflow...

  • Page 106: Generator Layout

    3 6 0 E X P R E S S G e n e r a t o r L a y o u t Forward CO Monitor AC/DC Panel 70A DPDT Breaker Generator Control Panel (Power Supply to AC/DC Panel) Aft CO Monitor All aft generator components are accessed by raising the...

  • Page 107: Bow Thruster & Power Assist Layout

    3 6 0 E X P R E S S B o w T h r u s t e r & P o w e r A s s i s t L a y o u t Bow Thruster Motor (accessed by removing stbd storage sump and two drawer cabinet) Emergency Shut-off Switch...

  • Page 108: Hardtop Accessories Layout

    3 6 0 E X P R E S S H a r d t o p A c c e s s o r i e s L a y o u t 6" Water Resistant Stereo Speakers Hardtop DC Dual Trumpet Horn Negative Bus (Accessed through...

  • Page 109: Stereo Layout

    3 6 0 E X P R E S S S t e r e o L a y o u t Sirius Antenna Sirius Tuner (behind microwave) Stereo 6 1/2" In-ceiling Stereo 6 1/2" In-ceiling Stereo Speaker Above Dinette Speaker Above Galley 6 1/2"...

  • Page 110: Volt Dc Accessory Locations

    3 6 0 E X P R E S S 1 2 Vo l t D C A c c e s s o r y L o c a t i o n s Anchor Windlass with Foot Controls and Solenoid Flat Panel TV &...

  • Page 111: Volt Ac Accessory Locations

    3 6 0 E X P R E S S 1 2 0 Vo l t A C A c c e s s o r y L o c a t i o n s Phone Jack & GFCI Cockpit Outlet 16,000 BTU Air Convection Microwave...

  • Page 112: Battery Wiring With Select Switches (Triple Engines)

    3 6 0 E X P R E S S B a t t e r y W i r i n g W i t h S e l e c t S w i t c h e s ( t r i p l e e n g i n e s ) BATTERY BATTERY 10 GA BLACK -...

  • Page 113: Battery Wiring With Select Switches (Dual Engines)

    3 6 0 E X P R E S S B a t t e r y W i r i n g W i t h S e l e c t S w i t c h e s ( d u a l e n g i n e s ) BATTERY BATTERY 10 GA BLACK -...

  • Page 114: Ac/Dc Panel Wiring - One-Line Diagram

    3 6 0 E X P R E S S A C / D C P a n e l W i r i n g – O n e - L i n e D i a g r a m GENERATOR SHORE # 1 AC VOLTS...

  • Page 115: Volt Dc Helm Switch Panel Diagram

    3 6 0 E X P R E S S 1 2 Vo l t D C H e l m S w i t c h P a n e l D i a g r a m MAIN TANK SENDER YAMAHA MULTI-FUNCTION...

  • Page 116: Volt Dc Lighting Diagram

    3 6 0 E X P R E S S 1 2 Vo l t D C L i g h t i n g D i a g r a m MAIN CABIN RECESSED LTS DIMMER SWITCH 16 GA BLU/GRN 16 GA BLU/GRN 16 GA BLK CABIN STEP &...

  • Page 117: Volt Dc Fuse Block Diagram

    3 6 0 E X P R E S S 1 2 Vo l t D C F u s e B l o c k D i a g r a m LINE SEE DWG SEE DWG 360-DC-1-1 360-DC-1-1 LINE 4 LINE 9 10 GA REDE...

  • Page 118: Volt Dc Wiper/Washer System Diagram

    3 6 0 E X P R E S S 1 2 Vo l t D C W i p e r / Wa s h e r S y s t e m D i a g r a m LINE FROM DWG 360-DC-3 LINE 11...

  • Page 119: Volt Dc Anchor Windlass Diagram

    3 6 0 E X P R E S S 1 2 Vo l t D C A n c h o r W i n d l a s s D i a g r a m FROM DWG FROM DWG LINE 360-DC-1-3...

  • Page 120: Volt Dc Hardtop Elementary Diagram

    3 6 0 E X P R E S S 1 2 Vo l t D C H a r d t o p E l e m e n t a r y D i a g r a m LINE SEE DWG 360-DC-1-1...

  • Page 121: Volt Dc Trim Tab Diagram

    3 6 0 E X P R E S S 1 2 Vo l t D C T r i m Ta b D i a g r a m LINE SEE DWG SEE DWG 360-DC-5 360-DC-5 LINE 7 LINE 7 BENNETT 14 GA ORG Relay Module...

  • Page 122: Volt Dc Cockpit Switch Panel Diagram

    3 6 0 E X P R E S S 1 2 Vo l t D C C o c k p i t S w i t c h P a n e l D i a g r a m F R O M D W G L IN E F R O M D W G...

  • Page 123: Volt Dc Ignition Circuit & Trim Diagram

    3 6 0 E X P R E S S 1 2 Vo l t D C I g n i t i o n C i r c u i t & T r i m D i a g r a m SEE DWG SEE DWG LINE...

  • Page 124: Air Condition & Cockpit Coolers One-Line Diagram

    3 6 0 E X P R E S S A i r C o n d i t i o n & C o c k p i t C o o l e r s O n e - L i n e D i a g r a m LINE FROM DWG 360-AC-1 AIR/COOLER PUMP CB...

  • Page 125: Volt Dc High Bilge Water Alarm Diagram

    3 6 0 E X P R E S S 1 2 Vo l t D C H i g h B i l g e Wa t e r A l a r m D i a g r a m LINE SEE DWG SEE DWG...

  • Page 126: Stereo System Diagram With Satellite Radio

    3 6 0 E X P R E S S S t e r e o S y s t e m D i a g r a m w i t h S a t e l l i t e R a d i o KENWOOD SEE DWG SEE DWG...

  • Page 127: Tv/Dvd Diagram

    3 6 0 E X P R E S S T V / D V D D i a g r a m LINE SHORE CABLE TV INLET RG6 COAXIAL RG6 COAXIAL FLAT PANEL SELECTOR TELEVISION SWITCH BROADCAST ANTENNA RG6 COAXIAL 3C RCA CABLE DVD PLAYER NOTES:...

  • Page 128: Electrical Plug Connection Detail

    3 6 0 E X P R E S S E l e c t r i c a l P l u g C o n n e c t i o n D e t a i l P l u g P l u g T y p e P l u g...

  • Page 129: Registration Of Purchase

    IS TO BE SENT TO THE GRADY-WHITE FACTORY AND NO REPAIRS MADE WITHOUT SUCH WRITTEN AUTHORITY. Grady-White Boats, Inc. reserves the right to improve its product through changes in design or material without obligation to incorporate such changes on boats built prior to the implementation of respected change(s).
  • Page 130 I M I T E D A R R A N T Y Exclusions: This warranty specifically does not include the following: • Damage caused by abuse, negligence, vandalism, lack of maintenance, improper storage, or accident. • Any statements, representations, or warranties given by dealer or other third persons other than those provided within this warranty.
  • Page 131 I M I T E D A R R A N T Y ARRANTY LAIM ROCEDURES PON THE DISCOVERY OF A DEFECT THE OWNER IS TO PROMPTLY CONTACT THE RADY HITE DEALER FROM WHOM THE ORIGINAL RETAIL PURCHASER PURCHASED THE BOAT WHO WILL AFFECT THE CORRECTIVE ACTION UNDER THIS WARRANTY UPON PRIOR WRITTEN AUTHORIZATION FROM RADY HITE...
  • Page 132 I M I T E D A R R A N T Y 9–4...
  • Page 133 Transferable Warranty Form (Not for original owner use *) * Note: For second owner’s use in transferring remainder of 5 year hull structural warranty. Please complete the following: Hullid: _____________________________ Boat Model: _________________________ Name: _______________________________________________________ Address: _____________________________________________________ City: _________________________________ State: __________ Zip: _______________ Home Phone: __________________________Work Phone: __________________________ Last 4 digits of your Social Security Number (to be used for customer identification number): ___________...
  • Page 134 If yes, where is your second home? _______________________________ _______ CityState Thank you for completing this questionnaire. When we receive this information, you will automatically begin receiving our AnchorLine Newsletter. Please return this form to: Grady-White Boats, Customer Relations Dept., P.O. Box 1527, Greenville, NC 27835-1527...

Table of Contents
