Table Cutout Dimensions - InSinkErator PowerRinse PRP Series Installation, Care And Use Manual

The PowerRinse Waste Collection
®
System pump motor fan must have a
minimum of 1" of clearance from any
wall or obstruction in order to operate
correctly.
Figure 5. PowerRinse Waste Collection System Dimensions
®

TABLE CUTOUT DIMENSIONS

Use the dimensions from Figure 6 for Standard
(Model PRS) table cutout and Figure 7 for Pot/Pan
(Model PRP) table cutout. Weld the waste collector tray
to the underside of the table so the water nozzle is on
the same side as the dishwasher.
4 "
- 3 /
)
2 4 m m
8 . 7
( 6 2
Figure 6. Standard Table Cutout (Model PRS)
Product Overview
33"-36"
(838-914 mm)
28.93"-31.93"
(735-811 mm)
25.41"-28.41"
(645-722 mm)
7.93"-10.93"
(201-278 mm)
r
h e
a s
h w
D i s
t e r
W a
l e
z z
N o
w
F l o
s h
D i
35.5" (902 mm)
Pot/Pan (Model PRP)
23.75" (603 mm)
Standard (Model PRS)
24.95"
20"
(634 mm) (508 mm)
44.95"
(1142 mm)
If using in line with a dishwasher, it is recommended to
mount the waste collector tray a minimum of 24" away
from the loading end of the dishwasher to allow enough
table space for a dish rack.
2 "
- 1 /
)
3 6 m m
7 . 8
( 9 2
Figure 7. Pot/Pan Table Cutout (Model PRP)
