2562463A REV. A 509
Safety Message to Installers of Siren Speakers
People's lives depend on your proper installation and servicing of Federal Signal products. It is
important to read and follow all instructions shipped with this product and the original product. Listed below
are some other important safety instructions and precautions you should follow:
Before Installation
Qualifications
•
To properly install an electronic siren, you must have a good understanding of automotive electri-
cal procedures and systems, along with proficiency in the installation and service of safety warning
equipment. Always refer to the vehicle's service manuals when installing equipment on a vehicle.
Sound Hazards
•
Your hearing and the hearing of others, in or near your emergency vehicle, could be damaged by
loud sounds. This can occur from short exposures to very loud sounds, or from longer exposures to
moderately loud sounds. For hearing conservation guidance, refer to federal, state, or local recom-
mendations. OSHA Standard 1910.95 offers guidance on "Permissible Noise Exposure."
•
All effective sirens and horns produce loud sounds (120 dB) that may cause permanent hearing
loss. Always minimize your exposure to siren sound and wear hearing protection. Do not sound the
siren indoors or in enclosed areas where you and others will be exposed to the sound.
•
Federal Signal siren amplifiers and speakers are designed to work together as a system. Combining
a siren and speaker from different manufacturers may reduce the warning effectiveness of the siren
system and may damage the components. You should verify or test your combination to make sure
the system works together properly and meets federal, state and local standards or guidelines.
During Installation
•
DO NOT get metal shavings inside the product. Metal shavings can cause the system to fail. If drill-
ing must be done near the unit, place an ESD-approved cover over the unit to prevent metal shav-
ings from entering the unit. Inspect the unit after mounting to be sure there are no shavings present
in or near the unit.
•
DO NOT connect this system to the vehicle battery until ALL other electrical connections are made,
mounting of all components is complete, and you have verified that no shorts exist. If wiring is
shorted to vehicle frame, high current conductors can cause hazardous sparks resulting in electrical
fires or flying molten metal.
•
Be sure the siren amplifier and speaker(s) in your installation have compatible wattage ratings.
•
In order for the electronic siren to function properly, the ground connection must be made to the
NEGATIVE battery terminal.
•
Sound output will be severely reduced if any objects are in front of the speaker. If maximum sound
output is required for your application, you should ensure that the front of the speaker is clear of any
obstructions.
ESB-CRG07 Behind-Grille Speaker Mounting
System for 2006 to 2009 Dodge Charger
Advertisement
Table of Contents
Related Manuals for Federal Signal Corporation ESB-CRG07
Summary of Contents for Federal Signal Corporation ESB-CRG07
- Page 1 ESB-CRG07 Behind-Grille Speaker Mounting System for 2006 to 2009 Dodge Charger 2562463A REV. A 509 Safety Message to Installers of Siren Speakers People’s lives depend on your proper installation and servicing of Federal Signal products. It is important to read and follow all instructions shipped with this product and the original product. Listed below...
-
Page 2: Before You Begin
IMPORTANT: The ES100 and MS100 comply with the requirements of SAE J1849 EVS3 and CCR Title 13 Class A when they are used with Federal Signal Corporation electronic sirens. The ES100 and MS100 are compact speakers intended to be mounted with the supplied mounting system. -
Page 3: Preparing The Mounting Surface
ESB-CRG07 Compact Speaker Mounting Kit Table 1: Kit contents Qty. Description Part Number Bracket 8567190 Hardware Kit 8567169 Screw, 1/4" x 1.0", Self Drill Lockwasher, Split, 1/4" Overview Mounting kit 8567079-13 mounts either an ES100 or a MS100 compact speaker behind the vehicle grille in a 2006 to 2009 Dodge Charger. - Page 4 ESB-CRG07 Compact Speaker Mounting Kit Attach the speaker to the bracket with the two 5/16-18 serrated hex/washer-head bolts supplied with the speaker. Adjust the speaker so that the front face of the speaker is perpendicular to the ground and not touching any parts of the vehicle (Figure 2).
-
Page 5: Ordering Replacement Parts
ESB-CRG07 Compact Speaker Mounting Kit Wiring the Speaker Connect the speaker to the electronic siren: • To connect one speaker, connect the two leads from the speaker to the cable from the electronic siren. • To connect two speakers, it is necessary to connect them in phase. Connect the two red speaker leads to one lead of the cable from the electronic siren. - Page 6 ESB-CRG07 Compact Speaker Mounting Kit • The shipping method. • The model or part number of the product being returned. • The quantity of products being returned. • Drop ship information as needed. • Any estimate required. When you receive your RMA Number: •...
-
Page 7: Returning A Product To Federal Signal
ESB-CRG07 Compact Speaker Mounting Kit • Frequently inspect the speaker to ensure that it is clear of any obstruction, such as mud or snow, which will reduce maximum sound output. Signaling Limitations • Be aware that the use of your visual and audible signaling devices does not give you the right to force your way through traffic. - Page 8 ESB-CRG07 Compact Speaker Mounting Kit When you receive your RMA Number: • Write the RMA number on the outside of the box of returned items. • Reference the RMA number on your paperwork inside of the box. • Write the RMA number down, so that you can easily check on status of the returned equipment.
