WINDTECH ARIAL XS Flight Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
m a n u a l
A R I A L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARIAL XS and is the answer not in the manual?

Questions and answers

Related Manuals for WINDTECH ARIAL XS

Summary of Contents for WINDTECH ARIAL XS

  • Page 1 m a n u a l A R I A L...

  • Page 3: Flight Manual

    Windtech w w w . w i n d t e c h . e s A R I A L X S - S - M - L flight manual...

  • Page 4: Table Of Contents

    > index > warning & liability > congratulations ––––––––––––––––––––––––––––––– > construction & materials ––––––––––––––––––––––––––––– ––––––––––––––––––––––– > certification –––––––––––––––––––––––––––––––––– > best glide –––––––––––––––––––––––––––––––––––– > flight ––––––––––––––––––––––––––––––––––––––– ––––––––––––––––––––––––––––––––––––– -- launch –––––––––––––––––––––––––––––––––– -- strong wind > thermal flying –––––––––––––––––––––––––––––––– > flying in turbulence ––––––––––––––––––––––––––––...
  • Page 5 We always appreciate your feedback, so please always send us your comments and crit- icism regarding Windtech products and service. are always happy to give you any help & advice. You will find more information on our You are the best feedback and support for future products, and please remember that we website www.windtech.es...

  • Page 6: Warning & Liability > Congratulations

    Windtech taken a training course, and has the ability and enough experience to safely fly the This manual cannot be used for operational purposes. The flight log & registration card ARIAL.

  • Page 7: Certification

    > certification The ARIAL is a paraglider of an intermediate level that has passed easily the tests of the DHV level 1. This glider has successfully passed the DHV shock test with a weight equal to the maximum total (all up) take-off weight. This means that the paraglider is certified to resist to a load of 8 (eight) times the gravitational acceleration (8 G´s).

  • Page 8: Flight

    38 cm between karabiners. For you own safety, we strongly recom- mend the use of back protection, helmet WindSOS reserve. Windtech -- launch Choose an open space free of any obsta- cles, especially trees and power lines.

  • Page 9: Thermal Flying

    There are many reverse launch methods/techniques which the pilot can learn. To progress well with your flying, and to be a good pilot, it is necessary to master at least one of the a better, safer pilot in the air & this will also help you to understand the dynamics of a techniques.

  • Page 10: Asymmetric Tuck

    better to under-react than to over-react. Over reacting to a situation can prevent the glider from self-recovering, and recovering air speed, and cause it to enter further unsta- ble situations. -- asymmetrical tuck/collapse An asymmetric tuck / collapse is when part (one side) of the wing ( say 20% or even any- thing up to 90% of the span) tucks or collapses, usually induced by turbulence but some- times also though poor pilot control in turns and wing-overs.

  • Page 11: Asymmetric Stall (Spin)

    recovery. Do not brake when the glider is behind you, as this can stall the wing, but wait for the glider to come forwards above your head, then brake. -- asymmetric stall (spin) This is a very difficult situation for the pilot to provoke with the ARIAL, given it's very low stall speed, you have to really abuse the controls a lot to manage it.

  • Page 12: Emergency Procedures & Quick Descent Techniques > Weather To Fly

    leading edge it is possible to burst the inner cells and walls of the wing and you should carefully examine the wing for any damage to the joining of the ribs to the cells. > weather to fly you should check the weather forecast & always ask more experienced pilots about the If in doubt about the weather and flying conditions, do not launch! Before going flying conditions expected for the day.

  • Page 13: B Stall

    one brake harder and harder and weight shifting into the turn. Pull more inside brake, and weight shift harder, for a faster spiral dive. Ease off on the inside brake, and weight- shift less hard, to regain level flight. Like this, the pilot can control the bank angle and the sink rate of the glider in the Spiral dive.

  • Page 14: Maintenance

    We strongly recommend you to have a full inspection of the paraglider by Windtech the distributor at least once a year. Besides this you should check periodically the lines, cloth and stitching.

  • Page 15: Technical Specifications

    ARIAL | technical specifications | Size Area (m 25,45 27,45 29,55 31,69 Projected area (m 22,48 24,33 26,10 28,01 Span (m) 10,82 11,25 11,65 12,07 Project. span (m) 8.74 9,07 9,73 Aspect ratio 4,64 4,64 4,64 4,64 Project. aspect ratio. Max .chord (m) 2,95 3,06...
  • Page 17 A R I A L L...
  • Page 18 A R I A L M...
  • Page 19 A R I A L S...
  • Page 20 A R I A L X S...
  • Page 21 Á Á A=340 mm B=370 mm =500 mm C=430 mm D=500 mm...

  • Page 22: Flight Log

    A R I A L | flight log | s s i i z z e e d d a a t t e e s s i i t t e e d d u u r r a a t t i i o o n n f f l l i i g g h h t t d d e e t t a a i i l l s s...
  • Page 24 · 7 33201 g i j ó n spain | p.o. box · 269 33280 | p# · +34 985 357 696 | fax · +34 985 340 778 | email · info@windtech.es | web · www.windtech.es POWERED BY WINDTECH...

This manual is also suitable for:

Arial sArial mArial l
