WELCOME
to the HERGÓM family. We would like to thank you for the distinction you have
made by choosing our BENNINGTON WOOD BURNING STOVE.
All of its parts are made of cast iron to guarantee a long working life.
We are sure your new stove will give you satisfaction on many occasions,
which is the greatest attraction of our equipment.
Owning a Hergóm Stove is a sign of an exception sense of quality.
Please read all of the manual. Its aim is to familiarise you with your stove,
indicating standards for its installation, operating and maintenance that will be
very useful to you. Please keep it and consult when necessary.
If after
reading this manual you require any further information, please do not hesitate
to contact your normal supplier or to call the factory directly.
IMPORTANT WARNING: If the fireplace is not suitably installed, the excellent
services for which it has been designed will not be given. Please ready these
instruction fully and entrust the work to a specialist.
Your Cast Iron Stove is protected on the inside with an anti-calorific paint
especially for high temperatures. When the stove is lit for the first few times, it
is normal for a slight amount of smoke to be produced when some of its
components evaporate, giving the paint body. We therefore recommend you
ventilate the room until this disappears.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BENNINGTON and is the answer not in the manual?

Questions and answers

Related Manuals for hergom BENNINGTON

Summary of Contents for hergom BENNINGTON

  • Page 1 WELCOME to the HERGÓM family. We would like to thank you for the distinction you have made by choosing our BENNINGTON WOOD BURNING STOVE. All of its parts are made of cast iron to guarantee a long working life. We are sure your new stove will give you satisfaction on many occasions, which is the greatest attraction of our equipment.
  • Page 2 1.- PRESENTATION The BENNINGTON Wood burning stove has the following main characteristics: Made completely of cast iron, with assembled parts sealed with ceramic rope and screwed • together. • External natural convection chamber between the double walls of the sides, rear and roof that increases the output of the stove and ensure a long working life.

  • Page 3: Installation

    The BENNINGTON mod. Stove produces a gentle, uniform and radiant heat that leads to pleasant comfort in your home.
  • Page 4 Other factors affect the draught: - Houses with extremely indoor insulation, without air currents: with no air entering the stove, the draught is affected. This is correct by sending air from outside to the stove. - Trees and/or tall buildings close to the home. - The wind speed.

  • Page 5: C.- Connecting The Chimney

    The advantages of metal chimneys are: • Easy installation. • Slight changes in chimney direction can be made, leading to greater flexibility in the choice of location for the stove. Due to there being curved elbow joint, sharp edges that make draught difficult •...

  • Page 6: D.- Some Standards

    Bear in mind that the tubes may pass through ceilings and walls. This must always be done using insulated tubes and suitable accessories. (See Fig. 4) D.- SOME STANDARDS Below are other standards that must be respected when building the chimney: a) Use resistant and non-combustible materials.
  • Page 7 e) It is very important for the tube joints to be well sealed to cover possible cracks that allow air to enter. Fig.-9 f) To check the airtightness of the chimney, cover the roof end and introduce paper with damp straw into the chimney. Fig.-10 g) It is very important for the chimney to stand out by more than one metre from the highest part of the house.
  • Page 8 h) The cowls must not hinder the draught. Fig.-12 Clean the chimney at least once a year. Fig.-13 j) The joints of the tubes forming the chimney, in the event of using simple metal tubes, must be sealed using refractory filler. Each tube must fit into the next to prevent any creosote from reaching the outside.

  • Page 9: A.- Controls And Features

    3.- OPERATING Once your Bennington stove has been installed and connected to the chimney, you are ready to light the fire. • BE CAREFUL!: THIS OPERATION PRODUCES HEAT. KEEP CHILDREN, CLOTHING AND FURNITURE AT A DISTANCE. CONTACT WITH THE STOVE MAY CAUSE SKIN BURNS.

  • Page 10: C.- Lighting Your Stove

    B.- FUELS Your Bennington wood burning stove is only designed to burn hardwood with a high calorific power. PRECAUTION DO NOT USE CHEMICAL FLUIDS OR INFLAMMABLES SUCH AS PETROL, NAPHTALENE, KEROSENE, DIESEL OILS, OILS, PELLETS, ARTIFICIAL WOOD OR ANY OTHER MATERIAL TO LIGHT YOUR STOVE. DO NOT BURN RUBBISH.

  • Page 11: Lighting The Stove For The First Time

    Where considered necessary, open a window to ventilate the room. The smoke and gas will normally remain for the first 10 or 20 minutes after lighting. The smells and smoke will disappear when the stove is “seasoned”. The first few times the stove is lit, other smells may be produced from the materials in the area near to the stove.
  • Page 12 i) Light the tablets. Leave the front door ajar until the kindling begins to burn and the draught begins to rise. j) Close the door and allow the fire to light. k) Once the kindling is lit, open the door and add logs, first small ones, to form the fire.

  • Page 13: Maintenance

    o OPERATING ERROR: Ensure that all joints are in a good state of repair. Replace any frayed or compressed joints. Do not light the stove with the front, side or cinder door open. Controlling the temperature is the best way of determining whether the stove has an excessive fire.
  • Page 14 9. Position the new joint in its place on the joint cement without pulling the material. 10. Close the door immediately to press the joint into place to ensure a valid seal. The following joints must be used: GLASS: 105 cm in length and 5 mm in thickness, (Code J316) FRONT LEFT DOOR: 82 cm in length and 10 mm in diameter.

  • Page 15: D.- Collecting And Disposing Ofashes

    11. Apply penetrating oil to the glass clamping screws. Remove the screws and lift up the clamps and the ceramic fibres below them. 12. Carefully lift the damage door glass and throw it away. 13. Where necessary, replace the ceramic fibre beading. Pull it out of position and clean away any remains.

  • Page 16: At The End Of The Season

    F.- CONTROLS Your stove is an appliance that is subject to extreme temperatures and to the corrosive effect of combustion waste. Its periodic maintenance is vital for a longer working life and better use. For this, we recommend you frequently carry out the following controls: 1.- DURING THE SEASON OF USE a) Visually inspect the chimney.

  • Page 17: Products For Preservation

    To delay general cleaning, we recommend the periodic use of the HERGÓM Anti- soot product, which can be found in any of our Distributors. 5.- PRODUCTS FOR PRESERVATION Industrias HERGÓM S.A. supplies a series of products for the preservation of your Stove and chimney: Heat resistant paint, refractory filler, anti-soot, lighting tablets, glass cleaner, etc.

  • Page 18: Draught Problems

    These same distances may be respected when the covering of walls or nearby areas is susceptible to damage or deformity by the temperature (varnishes, paints, P.V.C., etc.). DISTANCES TO SURFACES PARALLEL WALLS SLANTING WALLS SINGLE WALL CONNECTOR 1700 DOUBLE WALL CONNECTOR 1650 %(11,1*721 ',67$1&(6 )520...

  • Page 19: A Troubleshooting

    Below is a troubleshooting guide that will help you solve any problems with your stove: A.- TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTIONS Smoke comes out of Inappropriate handling of Open the primary air fully for one minute. Then open the door. the stove the stove Cold chimney...

  • Page 20: Technical Data

    8.- TECHNICAL DATA Specifications for the BENNINGTON mod. HERGÓM stove Maximum power WOOD (Oak, beech, etc.) 13,1 Kw Suitable for logs of wood up to a length of: 570 mm. Front Door: Height 352 mm. Width 536 mm. Side Door:...
