- Page 1 Serial Number: Model: INSTALLATION/OPERATORS MANUAL ACCU-STEAM ELECTRIC G2 GRIDDLE MODELS EGF24A EGF36A EGF48A EGF24B EGF36B EGF48B AccuTemp Products INC 8415 N. Clinton Park Dr, Fort Wayne IN 46825 www.accutemp.net MP5018-1912...
-
Page 2: Table Of Contents
TABLE OF CONTENTS DESCRIPTION PAGE Table of Contents / Document History Safety Warnings General Info Start up Form 8-10 Installation 11-13 Operation 14-24 Planned Maintenance Service & Troubleshooting 26-27 Warranty Information 28-30 DOCUMENT HISTORY Current Revision Date Prior Revision Date Revision MP5018-1912 08/26/2019... -
Page 3: Safety Warnings
1. WARNING SYMBOL DEFINITIONS SYMBOL DEFINITIONS Symbols are used to attract your attention to possible dangers. They are only effective if the operator uses proper accident prevention measures. Some of the symbols are boxed text; while others maybe just picture icons. Please give this information the respect they deserve for safe operation. - Page 4 1.1 IMPORTANT FOR YOUR SAFETY The safety instructions listed below on this page should be posted in a prominent location as a reminder of safe practices as well as recommended actions to follow in the event of an equipment or facility utility issue. WARNING In the event of a power failure, do not attempt to operate this appliance.
- Page 5 Intended for other than household use. or generic replacements parts do not have the same specifications to operate safely in AccuTemp equipment. It is imperative that to Plug the appliance into a properly use Genuine AccuTemp Replacement Parts grounded electrical outlet of the correct to avoid injury or damage to the commercial voltage, size and plug configuration.
- Page 6 Temperatures in and around the appliance are very hot and can cause severe burns. To avoid damage to the cooking surface of this appliance do not use abrasive cleaners such as a griddle stone or brick. To avoid personal injury or damage to the appliance do not use a water jet to clean the unit.
-
Page 7: General Info
(COOKING WIDTH) (COOKING WIDTH) (COOKING WIDTH) Fig 2.A MM5206-1812 UNIT DEPTH AccuTemp Products, Inc. 8415 North Clinton Park • Fort Wayne, IN 46825 • 800-210-5907 • 260-493-0415 • Fax 260-493-0318 • accutemp.net (COOKING HEIGHT) (COOKING DEPTH) 13.24 17.31 (COOKING DEPTH) EGFXXXXXXXX-T1... - Page 8 2.2 EQUIPMENT DATA PLATE AA B CCC D E FF GG Model: Example: EG F 120 1 A 48 50 A is the base model E = electric B is the model configuration CCC is the supply Voltage D is the number of phases: 1 or 3 E is the depth F is the width G is the special configuration...
- Page 9 1. Complete the Installation/Operational Checklist and Warranty Registration Form on the following two pages. 2. Mail, fax or scan and e-mail the form to AccuTemp Products, Inc to the contacts listed for each type on the form. 3. OR use the following link and upload a copy of the Installation/Operational Checklist and Warranty Registration Form online: https://www.accutemp.net/warranty-registration/...
-
Page 10: Start Up Form
Technicians Email: Email: Additional Info: • AccuTemp Products, Inc. is not responsible for the installation and/or modifications to the electrical supply source. • It is recommended that the wall receptacle be placed as low as State and Local codes allow. - Page 11 ACCU-STEAM Electric Griddle Start-Up Form (continued) 8. Is the correct NEMA Plug and Receptacle being used on the supply power cord?(Tick Box) Type of NEMA Plug Tick One 15-50P (208/240V) L16-20P (440/480 24” MDL) L16-30P (440/480 36” & 48” MDL) Temperature Verification 1.
-
Page 12: Installation
The ACCU-STEAM™ electric appliance has been Phillips Screw Driver designed to be placed on a commercial kitchen Small Blade Straight Screw Driver counter-top, an AccuTemp griddle stand or Digital Clamp Ammeter directly onto any flat, non combustible level Multimeter surface that will support the appliance weight. - Page 13 21A / 16 kW 21A / 16 kW 21A / 16 kW 21A / 16 kW The electrical voltage requirement is If mounted to an AccuTemp griddle stand with 480/3 Amp Load 16A / 13kW 16A / 13kW 23A / 19kW...
- Page 14 Electrical requirements are listed on the data plate located on the front right of the NEMA 6-50R control panel. All standard AccuTemp griddles 240V Single Phase are supplied with a 6ft (1.83m) cord and the appropriate UL listed plug that must be connected to the correct voltage specified on the units data tag.
-
Page 15: Operation
4.1 OPERATION INTRODUCTION 4. OPERATION RISKS RESULTING FROM CONTACT WITH The ACCU-STEAM G2™ griddle is constructed VERY HOT OBJECT: and uses technology like no other griddle in the world. The stainless steel cooking surface is heated by steam. The griddle steam chamber requires no additional liquid or maintenance. - Page 16 4.2 VISUAL IDENTIFICATION Stainless Steel Cooking Surface Overfill Grease Drawer Hole Display/Operational Keypad Grease Drawer Data Tag Adjustable Bullet Feet Fig 4.B Data Tag Display/Operational Keypad Tech Support Contact Info Operation/Fault Indicators Fig 4.C MP5018-1912 Accu-Steam Electric Griddle...
- Page 17 4.2 CONTROL OVERVIEW The appliance digital temperature control is easy to operate and requires little customer interface. OPERATOR DISPLAY AND KEYPAD 200F OPERATOR DISPLAY LED 1 LED 3 LED 2 PROGRAM KEY PRESET TEMP 1 KEY PRESET TEMP 2 KEY ASTERISK KEY PROGRAM KEY ON/OFF...
- Page 18 4.2.1 PROGRAM SEQUENCE OF 4.2.2 MANAGER MODE PROGRAMMING OPERATION Prior to using the commercial appliance a few Press the ON/OFF switch and the griddle operational items need to be determined. will start to pre-heat and LED 1 will blink Any •...
- Page 19 Managers mode is used to setup initial operational parameters for the appliance prior to the first time of production use. Manager’s mode 1. Entering Managers mode, press and hold the DOWN arrow key and the ASTERISK key together for about eight seconds, to initiate the programming mode. When the mode is accessed, all three LED lights will blink synchronously.
- Page 20 4.2.3 CONTROL REFERENCE GUIDE MODE LED Indicators DISPLAY NOTES All LED’s are off when Off when powered down. On/Off key. To turn unit on: depress the powered down. When powered On, the To turn off the unit, disable outputs, save the controller would FLASH current set point temperature (see details in at a 1 Hz rate the current...
- Page 21 MODE LED Indicators DISPLAY NOTES Set Preset All indicator LEDs Set Point Value Use the same process to change the Temperature blinking. Then the temperature as detailed in Set Temperature selected preset key (On the fly), to adjust the Set Temperature. will blink for 3 -5 Once the correct temperature is displayed, seconds.
- Page 22 4.3 COOKING 4.3.1 CLEAN AFTER INSTALLATION 400° F (204°C). The appliance will be preheated when the selected set temperature is displayed It is recommended that you clean your and the corresponding LED goes solid. Please ACCU-STEAM™ griddle thoroughly before use caution as temperatures on and around using it for the first time.
- Page 23 4.3.4 SURFACE TEMPERATURES The digital temperature control and temperature sensor are more accurate than any other device to measure the cooking surface temperature in this appliance. Any other digital device may show a difference. The important use of the external temperature measuring device is to ascertain that the temperatures are within ±5°F across the entire cooking surface of the appliance.
- Page 24 ™ G GG S 4.3.5 CHECKING SURFACE 4.3.6 GREASE TRAY TEAM RIDDLE The grease tray is located on the front TEMPERATURES Gas/Steam-Heated, right side of the appliance and has Tabletop Griddle a gripping handle on the front and 1. Verify griddle is level front to back and side to the inside middle to assist in safely side before attempting this procedure.
- Page 25 4.4 CLEANING • After the non-cooking surfaces are cool Always disconnect from power source to the touch. Empty the grease tray and before cleaning or servicing. wash with a mixture of dish detergent and clean water and dry with a clean dry cloth.
-
Page 26: Planned Maintenance
5. PLANNED MAINTENANCE CHECKLIST It is recommended that you contact your AccuTemp authorized service provider to setup a planned maintenance program to keep your appliance operating in the most efficient manner. AccuTemp recommends a minimum of a yearly schedule. PM TASK DESCRIPTION... -
Page 27: Service & Troubleshooting
Use of any replacement parts other temperatures. than those supplied by AccuTemp can • Contact AccuTemp Technical Service for cause injury to the operator or damage additional instructions. - Page 28 To correct, turn the appliance off and wait one minute and turn the appliance back on. If problem persists - call AccuTemp Service Fig 6.A Over-Temp Light (Heat light will also be...
-
Page 29: Warranty Information
• Be prepared to complete a few simple tasks to help evaluate the problem. • If the problem requires service at the location the AccuTemp Technical Service group will dispatch the nearest authorized service agent. AccuTemp Technical Service must be Service should be completed by contacted for all warranty service requests. - Page 30 One Year Parts and LaborOne Year Parts and Labor AccuTemp Products, Inc. ( AccuTemp ) warrants that your AccuTemp equipment will be free of defects in material and workmanship under normal use for a period of twelve (12) months from installation or fifteen (15) months from date of shipment from AccuTemp, whichever date first occurs (the Warranty Period ).
- Page 31 Damage to AccuTemp equipment that occurs during shipment must be reported to the carrier, and is not covered under this warranty. The reporting of any damage during shipment is the sole responsibility of the commercial purchaser/user of such AccuTemp equipment.
- Page 32 IMPORTANT SERVICE INFORMATION AccuTemp Product, Inc. Technical & Customer Support Technician is available Monday thru Sunday, 7:00am to 7:00pm EST.
