POOL SETUP (continued)
• Use a large mason rule (aluminum or wood)
2.2
and a level. Level out the ground by cutting
rectangles (or squares), locating this rule in
the selected and cleaned area (see
drawing 2.2).
A
4. Finishing
• On the cleaned and leveled ground, spread a light coat of sieved dirt to a maximum depth of 1/2 inch
(1 cm). Spray water and compact it (with a garden roller). Double check and ensure it is well leveled.
The ground has to be perfectly level in order to proceed further.
5. Patio block installation
• Purchase 15 pieces of patio block for 15'8" pool or 16 pieces of patio block for 16'8" pool or 18 pieces
for 18'8" pool. The minimum dimensions of each block should be 18" x 18" x 2". Mark the area where
the blocks will be buried (see drawing 3.1), then remove 2" (5.08 cm) of soil from the marked area
(see drawing 3.2).
• For 15'8" (478 cm) pool, where
A = 8'3" (251.5 cm) = Radius of grass area need to be removed and leveled.
B = 3'5" (104.1 cm) = Distance between each Patio Block.
For 16'8" (508 cm) pool, where
A = 8'9" (266.7 cm) = Radius of grass area need to be removed and leveled.
B = 3'5" (104.1 cm) = Distance between each Patio Block.
For 18'8" (569 cm) pool, where
A = 9'9" (297.1 cm)
B = 3'5" (104.1 cm)
3.1 3.2
B
A
2" (5.08 cm)
• The top of blocks should be flush with soil surface and level with the area surface and with all patio
blocks around entire pool (see drawing 3.3).
3.3
SAVE THESE INSTRUCTIONS
