Technical Specifications

Table 9: IOM37 Technical Specifications
Product Code Number
Supply Voltage
Power Consumption
Ambient Conditions
Addressing
Communications Bus
Processor
Memory
Input and Output Capabilities
Analog Input/Analog Output
Resolution and Accuracy
Terminations
Mounting
Housing
Dimensions(Height x Width x
Depth)
Weight
IOM3711 Input/Output Module Installation Instructions
MS-IOM3711-0U Input/Output Module
24 VAC (nominal, 20 VAC minimum/30 VAC maximum), 50/60 Hz, power supply Class 2
(North America)
14 VA maximum
Note: VA rating does not include any power supplied to the peripheral devices connected
to Binary Outputs (BOs) or Configurable Outputs (COs), which can consume up to
12 VA for each BO or CO; for a possible total consumption of an additional 48 VA
(maximum).
Operating: 0° to 50°C (32° to 122°F); 10% to 90% RH noncondensing
Storage: -40° to 80°C (-40° to 176°F); 5% to 95% RH noncondensing
DIP switch set; valid expansion module device addresses 4–127
(Device addresses 0–3 and 128–255 are reserved and not valid expansion module
addresses.)
BACnet® MS/TP, RS-485:
3-wire FC bus between the supervisory controller and other controllers
4-wire SA bus between controller, network sensors and other sensor/actuator devices,
includes a lead to source 15 VDC supply power (from controller) to bus devices.
H8SX/166xR Renesas® 32-bit microcontroller
512 KB Flash Memory and 128 KB Random Access Memory (RAM)
4 - Universal Inputs: Defined as 0–10 VDC, 4–20 mA, 0–600k ohm, or Binary Dry Contact
4 - Universal Outputs: Defined as 0–10 VDC, 4–20 mA, or 24 VAC/DC Field-Effect Transistor
(FET) BO
4 - Relay Outputs: (Single-Pole, Double-Throw)
UL Listed (-0 model only): 1/4 hp 120 VAC, 1/2 hp 240 VAC; 360 VA Pilot Duty at 120/240
VAC (B300); 3 A Non-inductive 24-240 VAC
CE Marking (-2 model only): 6 (4) A N.O. or N.C. only, 240 VAC
Input: 16-bit resolution
Output: 16-bit resolution, +/- 200 mV accuracy in 0–10 VDC applications
Input/Outputs: Fixed Screw Terminal Blocks
SA/FC Bus and Supply Power: 4-Wire and 3-Wire Pluggable Screw Terminal Blocks
SA/FC Bus Port: RJ-12 6-Pin Modular Jacks
Horizontal on single 35 mm DIN rail mount (preferred), or screw mount on flat surface with
three integral mounting clips on expansion module
Enclosure material: ABS and polycarbonate UL94 5VB; Self-extinguishing, Plenum Rated
150 x 190 x 53 mm (5-7/8 x 7-1/2 x 2-1/8 in.) including terminals and mounting clips
Note: Mounting space requires an additional 50 mm (2 in.) space on top, bottom and front
face of expansion module for easy cover removal, ventilation and wire terminations.
0.5 kg (1.1 lb)
