Technical Specifications - Johnson Controls IOM2710 Installation Instructions Manual

Table 5: FEC/IOM Accessories (Order Separately) (Part 2 of 2)
Product Code
Number
AP-TBK4SA-0
AP-TBK4FC-0
AP-TBK3PW-0
MS-BTCVT-1
MS-BTCVTCBL-700

Technical Specifications

IOM2710 and IOM3710 Input/Output Modules (Part 1 of 2)
Product Code Numbers
Supply Voltage
Power Consumption
Ambient Conditions
Terminations
Controller Addressing
Communications Bus
Analog Input/Analog Output
Resolution and Accuracy
Mounting
Dimensions
(Height x Width x Depth)
Housing
Weight
Description
Replacement MS/TP SA Bus Terminal, 4 Position Connector, Brown, Bulk Pack
Replacement MS/TP FC Bus Terminal, 4 Position Connector, Blue, Bulk Pack
Replacement Power Terminal, 3 Position Connector, Gray, Bulk Pack
Wireless Commissioning Converter, with Bluetooth technology
Cable replacement Set for the MS-BTCVT-1 or the NS-ATV7003-0; includes one 5-foot
retractable cable.
MS-IOM2710-0
MS-IOM3710-0
20-30 VAC at 50 or 60 Hz, Class 2 or Safety Extra Low Voltage (SELV)
10 VA typical, 14 VA maximum plus all BO and Configurable Output loads
Operating: 0 to 50°C (32 to 122°F); 10 to 90% RH noncondensing
Storage: -40 to 70°C (-40 to 158°F); 10 to 90% RH noncondensing
Screw terminals, 3-Position Screw Terminal Pluggable Blocks, 4-Position Screw Terminal
Pluggable Blocks
DIP switch set (4-127). Addresses 1-3, 128-255 are reserved.
BACnet® MS/TP; 3-wire FC Bus between the NAE/NCE and other devices. 4-wire SA Bus
when used as expansion to FEC.
Analog Input: 16-bit resolution
Analog Output: 16-bit resolution and ±200 mV in 0-10 VDC applications
On flat surface with screws on three mounting clips or a single 35 mm DIN rail
IOM2710: 180 x 127 x 58 mm (7-1/16 x 5 x 2-1/4 in.)
IOM 3710: 180 x 127 x 58 mm (7-1/16 x 5 x 2-1/4 in.)
Plastic housing
Plastic material: ABS + polycarbonate UL94 5VB
Protection: IP20 (IEC529)
IOM2710: 0.48 kg (1.1 lb)
IOM 3710: 0.55 kg (1.2 lb)
IOM2710 and IOM3710 Input/Output Modules Installation Instructions
1
9
