3. Drill holes in the wall or surface at the marked
locations, and insert appropriate wall anchors in the
holes (if necessary).
4. Hold the expansion module in place, and insert the
screws through the mounting clips and into the holes
(or anchors). Carefully tighten all of the screws.
Important: Do not overtighten the mounting screws.
Overtightening the screws may damage
the mounting clips.
Table 1: IOM3711 Physical Features
Callout Physical Feature: Description and References
1 Relay Output Terminal Blocks. (See
2 Mounting Clip
3 Device Address DIP Switch Block. (See
4 Universal Outputs (UOs) Terminal Blocks. (See
5 24 VAC, Class 2 Supply Power Terminal Block. (See
IOM3711 Input/Output Module Installation Instructions
Figure 3: IOM3711 Physical Features
Table 3)
Setting the Device
Input and Output Terminal
Figure 2: Back of Expansion Module Showing
Extended Mounting Clips, DIN Rail Channel, and
Mounting Dimensions, mm (in.)
Addresses)
Blocks)
Table 5)
