Control with External Signals (Continued)
Input Signal and Photocoupler
The input signal from the external control connector turns the photocoupler
inside the Control Unit ON and OFF to set and write data. The input signal is
compatible with both the sinking and sourcing devices.
For a sinking device, the photocoupler is OFF when the input signal is high, and
for a source type, the photocoupler is ON when the input signal is high.
Signal input
HIGH
Sinking
LOW
HIGH
Sourcing
LOW
External Signal Connection Example
Sinking
External Circuits
24V DC
Light intensity
Transistor (NPN)
open collector
Sourcing
External Circuits
24V DC COMMON
Light intensity
Transistor (PNP)
open collector
ON voltage/
Rated Maximum
ON current
input voltage input voltage
14.4V DC min./
24V DC 26.4V DC
3 mA max.
Sequence Diagram for Writing Data
Channel Selection Input
CHSEL2 to CHSEL0
Light Intensity Input
B7 to B0
Light Intensity Write Input
BRTWR
Photocoupler OFF
Photocoupler ON
Lighting Mode Value Input
M3 to M0
Lighting Mode Write Input
TRGWR
Photocoupler OFF
Photocoupler ON
L1 light set value
(24V LIGHT)
L1 light set value
(HLV LIGHT)
L2 light set value
(24V LIGHT)
L2 light set value
(HLV LIGHT)
* The response times of the 24V LIGHT and the HLV LIGHT connectors are very different.
* If the data is rewritten during the response time for the light set value, the start of the rewrite that was input again is reset as the starting point.
Photocoupler Data
OFF 1
ON 0
ON 0
OFF 1
PD3 Control Unit
COMMON
12
12kΩ
22kΩ
input B0
1
PD3 Control Unit
12
12kΩ
22kΩ
input B0
1
Signal Specifications
OFF voltage/ Response time
Input impedance
OFF current
5V DC max./ 50us max. (24V LIGHT)
12 kΩ (per terminal)
1 mA max.
100ms max. (HLV LIGHT)
L1
Light intensity 1
200 µs min.
50 µs min.
Lighting mode 1 Lighting mode 1
200 µs min.
50 µs min.
50 µs max. *

Connector Layout

External Control Connector Plug
No.
Bit
1 B0
2 B1
3 B2
4 B3
5 B4
6 B5
7 B6
8 B7
9 CHSEL0
10 CHSEL1
11 CHSEL2
12 COMMON
13 BRTWR
14 TRGWR
15 M0
16 M1
17 M2
18 M3
19 OC
20 OE
300 µs min. 300 µs min.
50 µs min. 200 µs min.
300 µs min. 300 µs min.
50 µs min. 200 µs min.
100 ms max. *
7 7
Enlarged Cable Diagram
Example: Pin No. 10, pink, red 1
Signal
EXCB2-M20-3
Wire color Marks Wire color Marks
Orange Black 1
Orange Red 1
Gray Black 1
Light Intensity Gray Red 1
Input (8 bits) White Black 1
White Red 1
Yellow Black 1
Yellow Red 1
Pink Black 1
Channel Selection
Pink Red 1
(3 bits)
Orange Black 2
Orange Red 2
Light Intensity Write Gray Black 2
Lighting Mode Write
Gray Red 2
White Black 2
Lighting Mode Value Red 2
White
Input (4 bits) Yellow Black 2
Yellow Red 2
Pink Black 2
Error Output
Pink Red 2
L2
Light intensity 2
Lighting mode 2
Light intensity/lighting mode 1 Light intensity/lighting mode 1
Light intensity/lighting mode 1 Light intensity/lighting mode 1
Light intensity/lighting mode 2 Light intensity/lighting mode 2
50 µs max. *
Light intensity/lighting mode 2 Light intensity/lighting mode 2
100 ms max. *
Pink Red 1
Cable
EXCB2-M10M20-3
Orange Black 2
Red 2
Orange
Gray Black 2
Gray Red 2
White Black 2
White Red 2
Yellow Black 2
Yellow Red 2
Pink Black 2
Pink Red 2
Orange Black 3
Orange Red 3
Gray Black 3
Gray Red 3
White Black 3
White Red 3
Yellow Black 3
Yellow Red 3
Pink Black 3
Pink Red 3
