CCS PD3-3024-3-PT Instruction Manual

Control Unit for LED Light Units
PD3-3024-3-PT
With Parallel Communications
Instruction Guide
Thank you for purchasing a CCS product.
To ensure proper use of the product,
please read this Instruction Guide before
use and keep it for your future reference.
This Control Unit is specifically designed to control the light intensity of CCS
LED Light Units. It is mainly used to control LED Light Units that are used for
machine vision and industrial inspections.
Features
One Control Unit can individually control three different Light Units.
The light intensity can be manually controlled with a dial on the front panel, or externally controlled
using a PLC or machine vision equipment.
PWM control is used to control the light intensity at a frequency of 125 kHz.
Data can be written in high-speed with parallel external control.
External trigger inputs can be used to turn lights ON or OFF, or to strobe lights.
The Control Unit can be used for CCS LED Light Units with a voltage of 24 V and a
power consumption of up to 28 W.
The total power consumption of the connected Light Units must be 28 W or less.
1
Important Information for Equipment Safety
This product has been designed with full consideration of safety. Incorrect
usage of the product may result in fire, electric shock, or other serious
damages. Observe the following precautions.
The following symbols are used in this instruction guide to indicate and classify the
relative importance of warnings and cautions.
Indicates that incorrect
WARNING usage may result in
serious injury or death.
The following symbols in the instruction guide indicate and classify the precautions.
PROHIBITED DISASSEMBLY DO NOT TOUCH
PROHIBITED WITH WET HANDS
These symbols indicate prohibited actions.
Do not disassemble or modify the product.
Doing so may result in fire or electric shock.
DISASSEMBLY
Make sure that the product is free of
moisture or any liquid. Doing so may result
in fire or electric shock.
DO NOT SUBJECT
Do not touch the power cords during
lightning. This may result in electric shock.
Indicates that incorrect
Caution usage may result in injury
or property damage.
DO NOT SUBJECT MANDATORY
TO MOISTURE ACTIONS
This symbol indicates required actions.
WARNING
Do not touch the plugs or switches with wet
hands. Doing so may result in electric shock.
PROHIBITED
Before connecting or disconnecting cables,
make sure that the power source is turned
OFF. Not doing so may result in fire or
electric shock.
TO MOISTURE
If abnormal condition occurs such as fuming,
heat, smell, noise, or so on, stop using the
product immediately, and turn off the power
source. A fire or electric shock may result if
PROHIBITED
the product is kept used.
