CCS PD2 Series Instruction Manual

PD2 Single Channel Series Instruction Guide
PD2-1012(A)/1024(A)/3012(A)/3024(A)/5012(A)/5024(A)
1. Safety Precautions
Thank you for purchasing a CCS product. To properly use the product, please read this
instruction guide before use and keep it for your future reference. Be sure to pay special
attention to the information marked with "
provided to prevent injury from electric shock and other accidents.
Warning Indicates incorrect usage may result in serious injury or death.
Caution Indicates incorrect usage may result in injury or equipment damage.
(1) Always use one of the following power cords for the PD2-3012(A), PD2-3024(A),
and PD2-5012(A), PD2-5024(A).
100 to 120V range: SVT or SJT type, AWG18, length: 3m max. , dielectric
strength: 125V min. (Note: This power cord is required for compliance with UL)
200 to 240V range: H05VV-F type, AWG18, length: 3m max. , dielectric
strength: 250V min. (Note: This power cord is required for compliance with EU)
(2) Plug in or unplug the power cord after turning OFF the power supply.
Otherwise it may result in fire or electric shock. Plug the power cord directly
into the wall socket.
Please use the product within electricity voltage/current specifications.
Otherwise it may cause fire and/or electric shock.
Please unplug the power cord when connecting or disconnecting the product
and peripherals.
Do not damage or place heavy objects on power cord. There are risks of
damaging the cord, which may result fire or electric shock.
(3) If the product is damaged, turn it OFF, unplug the power cord from the wall
socket, and contact CCS. Continued usage of the product may result in fire or
electric shock.
(4) Follow the operating procedures stipulated for the product in this instruction guide.
Failure to do so may result in diminished protection capabilities.
(5) The product operates at a power supply voltage of 100 to 240V AC. The supplied power
cord, however, is for use with 100V. If the product is to be used at 200V or above, use a
200V power cord for the 30 and 50W models.
(6) For mounting products in system racks or cases, do not insert M3 type screws more than
6mm. (PD2-1012(A)/1024(A):2mm). Doing so may cause short-circuit to internal
components.
Do not disconnect power cord or disassemble product while operating.
(7)
Doing so may result in electric shock.
Do not touch the terminals, plugs, or switches with wet hands.
(8)
Doing so may result in electric shock.
Control Unit for LED Light Units
*Read this instruction guide before using the product.
Warning" and "
Warning
- 1 -
Caution". The information is
